Filters
Within Plant & Agriculture, Filters covers the engine, hydraulic, and equipment-system filters fitted to plant equipment, agricultural tractors, telehandlers, commercial vehicles, and the wider plant-and-vehicle filtration aftermarket — covering engine air filters (intake-air filtration, in panel and round-canister formats), engine oil filters (in spin-on, cartridge, and centrifugal-bypass formats), fuel filters (primary water-separator and secondary fine-fuel filters for diesel engines; in-line and cartridge formats), hydraulic filters (return-line, pressure-line, and suction-line filters for hydraulic-circuit cleanliness), cab air filters (for operator-cab HVAC systems — particle and activated-carbon filtration), and the matching filter housings, sealing rings, and service hardware.
Parts for Machines supplies filters across the plant, agricultural, and commercial-vehicle aftermarket. The category covers both OEM-pattern filters (matched exactly to specific equipment fitments by housing and filter dimensions) and high-quality aftermarket filters from specialist filter manufacturers.
Product pages list the filter type (engine air, oil, fuel, hydraulic, cab-air), the equipment application (the equipment make, model, and engine the filter fits), the OEM cross-reference part number, the filter dimensions (overall diameter, height, sealing-ring size), the filter rating (the smallest particle size filtered — typical 5-30 microns for hydraulic; 10-30 microns for fuel), the filter capacity (how much contamination the filter can hold before reaching pressure-drop limits), the filter media (paper, synthetic, glass-fibre, micro-glass for ultra-fine filtration), and any specific service-life specification.
For replacement of an existing filter, the OEM part number is the most reliable match. Filters have specific dimensional and filtration ratings — wrong-spec substitution gives inadequate filtration (engine wear, hydraulic-circuit contamination) or excessive flow restriction (engine starvation, hydraulic-pump damage). Always specify the OEM-equivalent filter for the equipment. Trade pricing on bulk service-pack orders is available; contact the team via WhatsApp 07754288583.
| Outer Diameter | 88 mm (3.47 inch) |
|---|---|
| Inner Diameter | 19 mm (0.75 inch) |
| Inner Diameter Bottom End | 19 mm (0.75 inch) |
| Length | 86 mm (3.39 inch) |
| Overall Length | 89 mm (3.50 inch) |
| Outer Diameter | 84 mm (3.31 inch) |
|---|---|
| Inner Diameter | 23.4 mm (0.92 inch) |
| Inner Diameter Bottom End | 23.4 mm (0.92 inch) |
| Length | 192.5 mm (7.58 inch) |
| Overall Length | 198.5 mm (7.81 inch) |
| Thread Size | 1 x 16 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 179 mm (7.05 inch) |
| Thread Size | G 3/4 BSP |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 71 mm (2.80 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 145 mm (5.67 inch) |
| Thread Size | 13/16 x 16 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 63 mm (2.48 inch) |
| Length | 84 mm (3.31 inch) |
| Thread Size | M 16 x 1.5 |
|---|---|
| Outer Diameter | 77 mm (3.03 inch) |
| Gasket OD | 70.2 mm (2.76 inch) |
| Gasket ID | 60.5 mm (2.38 inch) |
| Length | 97 mm (3.82 inch) |
| Thread Size | M 20 x 1.5 |
|---|---|
| Outer Diameter | 84 mm (3.31 inch) |
| Gasket OD | 78 mm (3.07 inch) |
| Gasket ID | 63 mm (2.48 inch) |
| Length | 119 mm (4.69 inch) |
| Thread Size | 1 x 14 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 179 mm (7.05 inch) |
| Outer Diameter | 95 mm (3.74 inch) |
|---|---|
| Inner Diameter | 34 mm (1.34 inch) |
| Inner Diameter Bottom End | 34 mm (1.34 inch) |
| Length | 195 mm (7.68 inch) |
| Overall Length | 196 mm (7.72 inch) |
| Thread Size | M 16 x 1.5 |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 71.6 mm (2.82 inch) |
| Gasket ID | 62.4 mm (2.46 inch) |
| Length | 209 mm (8.23 inch) |
| Outer Diameter | 76 mm (2.99 inch) |
|---|---|
| Inner Diameter | 76 mm (2.99 inch) |
| Inner Diameter Bottom End | 76 mm (2.99 inch) |
| Length | 51 mm (2.01 inch) |
| Overall Length | 51 mm (2.01 inch) |
| Length | 271 mm (10.67 inch) |
|---|---|
| Width | 133 mm (5.24 inch) |
| Height | 42 mm (1.65 inch) |
| Overall Height | 42 mm (1.65 inch) |
| Efficiency | Beta 1000 99.9% |
| Thread Size | M 22 x 1.5 |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 90 mm (3.54 inch) |
| Gasket ID | 77 mm (3.03 inch) |
| Length | 100 mm (3.94 inch) |
| Length | 314 mm (12.36 inch) |
|---|---|
| Width | 150 mm (5.91 inch) |
| Height | 58 mm (2.28 inch) |
| Overall Height | 58 mm (2.28 inch) |
| Efficiency | Beta 1000 99.9% |
| hread Size | 3/4 x 16 |
|---|---|
| Outer Diameter | 111 mm (4.37 inch) |
| Gasket OD | 72 mm (2.84 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 101 mm (3.98 inch) |
| Outer Diameter | 89 mm (3.50 inch) |
|---|---|
| Inner Diameter | 89 mm (3.50 inch) |
| Inner Diameter Bottom End | 89 mm (3.50 inch) |
| Length | 54.5 mm (2.15 inch) |
| Overall Length | 54.5 mm (2.15 inch) |
| Thread Size | 3/4 x 16 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 63 mm (2.48 inch) |
| Length | 174 mm (6.85 inch) |
| Thread Size | 1 x 12 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 62.5 mm (2.46 inch) |
| Length | 210 mm (8.27 inch) |
| Outer Diameter | 50 mm (1.97 inch) |
|---|---|
| Inner Diameter | 47 mm (1.85 inch) |
| Inner Diameter Bottom End | 47 mm (1.85 inch) |
| Length | 41 mm (1.61 inch) |
| Overall Length | 41 mm (1.61 inch) |
| Thread Size | 1 x 12 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 71 mm (2.80 inch) |
| Gasket ID | 61 mm (2.40 inch) |
| Length | 179 mm (7.05 inch) |
| Thread Size | M 16 x 1.5 |
|---|---|
| Outer Diameter | 80 mm (3.15 inch) |
| Gasket OD | 70 mm (2.76 inch) |
| Gasket ID | 60 mm (2.36 inch) |
| Length | 154 mm (6.06 inch) |
| Thread Size | M 22 x 1.5 |
|---|---|
| Outer Diameter | 78 mm (3.07 inch) |
| Gasket OD | 70 mm (2.76 inch) |
| Gasket ID | 60 mm (2.36 inch) |
| Length | 85 mm (3.35 inch) |
| Thread Size | 3/4 x 16 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 63 mm (2.48 inch) |
| Length | 97 mm (3.82 inch) |
| Length | 269 mm (10.59 inch) |
|---|---|
| Width | 188 mm (7.40 inch) |
| Height | 44.5 mm (1.75 inch) |
| Overall Height | 44.5 mm (1.75 inch) |
| Efficiency | Beta 1000 99.9% |
| Thread Size | 3/4 x 16 UN |
|---|---|
| Outer Diameter | 92 mm (3.62 inch) |
| Gasket OD | 63 mm (2.48 inch) |
| Gasket ID | 57 mm (2.24 inch) |
| Length | 136 mm (5.35 inch) |
| Thread Size | 3/4 x 16 UN |
|---|---|
| Outer Diameter | 98 mm (3.86 inch) |
| Gasket OD | 72 mm (2.84 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 152 mm (5.98 inch) |
| Thread Size | M 20 x 1.5 |
|---|---|
| Outer Diameter | 106 mm (4.17 inch) |
| Gasket OD | 88 mm (3.47 inch) |
| Gasket ID | 80 mm (3.15 inch) |
| Length | 123 mm (4.84 inch) |
| Thread Size | M 20 x 1.5 |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 50 mm (1.97 inch) |
| Length | 145 mm (5.71 inch) |
| Thread Size | M 20 x 1.5 |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 50 mm (1.97 inch) |
| Length | 145 mm (5.71 inch) |
| Thread Size | 3/4 x 16 |
|---|---|
| Outer Diameter | 111 mm (4.44 inch) |
| Gasket OD | 71 mm (2.80 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 149 mm (5.96 inch) |
