FAQs

ISO VG 46 is the default for the majority of UK plant, agricultural, and industrial hydraulic systems operating at moderate temperatures — that's what your equipment handbook will specify in most cases. ISO VG 32 is used in cold-climate operations or for systems running at lower temperatures. ISO VG 68 is used in high-temperature continuous-duty applications, often in summer-only or hot-environment use. Always default to the equipment handbook's recommendation rather than substituting a different grade.

HM (or HLP) is the standard anti-wear hydraulic oil specification — suitable for most plant and agricultural hydraulics. HV adds high-viscosity-index improvers, giving better cold-start performance and a wider operating temperature range. HEES (sometimes called HEES-S) is a zinc-free, biodegradable fluid used where environmental contamination is a concern — forestry, marine, and watercourse-adjacent applications. Castrol Hyspin AWS, Shell Tellus S2, and Q8 Holbein are HM/HLP-grade. Specialist HV and HEES grades are supplied on request — contact the team for availability.

Yes, in most cases — as long as both fluids meet the same specification (e.g. both are ISO VG 46, anti-wear HM grade, with compatible additive chemistry). Mixing brands within the same specification category will not damage the system. Avoid mixing across specification categories — for example, topping up a zinc-free HEES system with a standard zinc-additive HM oil will compromise the biodegradable properties. For full system flushes, complete a drain and refill rather than mixing.

Castrol Hyspin AWS, Shell Tellus S2 / S3, and Q8 Holbein and Heller hold approvals from the major plant OEMs including JCB, Volvo CE, John Deere, and Komatsu, as well as the German hydraulic specifications (DIN 51524-2 HLP, DIN 51524-3 HVLP). Check the specific OEM approval list on each product page against your equipment manufacturer's recommended fluids list. WhatsApp 07754288583 with the machine make and model if you need confirmation.

Returns are accepted within 30 days of purchase, in original packaging, on orders delivered within the United Kingdom. For damaged-on-arrival items, report within 24 hours with photographs to [email protected] — we will typically arrange collection and replacement at no cost to you. For parts that don't fit your machine, the Fit Guarantee covers a hassle-free return at no cost. For buyer's remorse — you've changed your mind or ordered the wrong item, email us first to obtain a Return Merchandise Number; a restocking fee may apply. Refunds are issued to the original payment method once the return is inspected.

Delivery time depends on the product, your destination, and availability — the estimated time for any item appears on the product page, and 'Check where we deliver' confirms coverage for your postcode before you order. Next-day delivery is available on most products; the option appears at checkout when applicable. We deliver across the UK, Europe, the Middle East, and Africa. Use the country selector at checkout to confirm coverage and delivery options for your destination.

Kinematic Viscosity at 40°C	32 mm²/s
Kinematic Viscosity at 100°C	5.5 mm²/s
Viscosity Index	108
Density at 15°C	862 kg/m³
Colour (ASTM)	0.5

ISO Viscosity Grade	32
Density, 15 °C	0,87 g/ml
Kinematic Viscosity, 40 °C	32.0 mm²/s
Kinematic Viscosity, 100 °C	5.33 mm²/s
Viscosity Index	98

ISO Viscosity Grade	46
Density, 15 °C	0.875 g/ml
Kinematic Viscosity, 40 °C	46 mm²/s
Kinematic Viscosity, 100 °C	8.15 mm²/s
Viscosity Index	152

ISO Viscosity Grade	32
Density, 15 °C	0,867 g/ml
Kinematic Viscosity, 40 °C	32.0 mm²/s
Kinematic Viscosity, 100 °C	6.35 mm²/s
Viscosity Index	154

ISO Viscosity Grade	68
Density, 15 °C	0,88 g/ml
Kinematic Viscosity, 40 °C	68.0 mm²/s
Kinematic Viscosity, 100 °C	8.66 mm²/s
Viscosity Index	97

Density @ 15°C / 59°F	880 kg/m³
Kinematic Viscosity @ 40°C / 104°F	68 mm²/s
Kinematic Viscosity @100°C / 212°F	8.6 mm²/s
Viscosity Index	>95
Pour Point	-21/-6 °C/°F

ISO Viscosity Grade	32
Density, 15°C	0.869 g/ml
Kinematic Viscosity, 40°C	32.0 mm²/s
Kinematic Viscosity, 100°C	5.4 mm²/s
Viscosity Index	102

ISO Viscosity Grade	22
Density @ 15°C / 59°F ISO 12185 / ASTM D4052	870 kg/m³
Kinematic Viscosity @ 40°C / 104°F ISO 3104 / ASTM D445	22mm²/s
Kinematic Viscosity @ 100°C / 212°F ISO 3104 / ASTM D445	4.3mm²/s
Viscosity Index ISO 2909 /ASTM D2270	>95

Kinematic Viscosity, -40 °C	1500 mm²/s
Kinematic Viscosity, 40 °C	7,9 mm²/s
Density, 20 °C	1.052 g/ml
Colour	Pale amber
Flash Point, P-M	110 °C

ISO Viscosity Grade	100
Density @ 15°C / 59°F ISO 12185 / ASTM D4052	890 kg/m³
Kinematic Viscosity @ 40°C / 104°F ISO 3104 / ASTM D445	100mm²/s
Kinematic Viscosity @ 100°C / 212°F ISO 3104 / ASTM D445	11.1mm²/s
Viscosity Index ISO 2909 / ASTM D2270	>95

ISO Viscosity Grade	68
Density, 15 °C	0.879 g/ml
Kinematic Viscosity, 40 °C	68 mm²/s
Kinematic Viscosity, 100 °C	8.7 mm²/s
Viscosity Index	99

Operating temperature	Max. 82°C
Viscosity	46 mm/s² at 40°C
Viscosity index	95
Oil type	Mineral
Product type	Lubricating Oils

ISO Fluid Type	HM
Kinematic Viscosity@32°F	580 cSt
Kinematic Viscosity@104°F	46 cSt
Kinematic Viscosity@212°F	6.9 cSt
Viscosity Index	105

ISO Viscosity Grade	32
Density @ 15°C / 59°F ISO 12185 /ASTM D4052	880 kg/m³
Kinematic Viscosity @ 40°C / 104°F ISO 3104 /ASTM D445	32 mm²/s
Kinematic Viscosity @ 100°C / 212°F ISO 3104 /ASTM D445	6.3 mm²/s
Viscosity Index ISO 2909 /ASTM 2270	>150

ISO Fluid Type	HM
Kinematic Viscosity@32°F	1000 cSt
Kinematic Viscosity@104°F	68 cSt
Kinematic Viscosity@212°F	8.9 cSt
Viscosity Index	105

Appearance	Clear and bright yellow liquid
Density @ 20C	1.07 g/ml
ERBP (Equilibrium Reflux Boiling Point)	260 °C
Viscosity, Kinematic -40C	1200 mm²/s
Wet Equilibrium Reflux Boiling Point	165 °C

Appearance	Clear and bright yellow liquid
Density @ 20C IP 160	1.07 g/ml
ERBP (Equilibrium Reflux Boiling Point)	260 °C
Viscosity, Kinematic -40C	1200 mm²/s
Wet Equilibrium Reflux Boiling Point	165 °C

ISO Fluid Type	HM
Kinematic Viscosity@0°C	340 cSt
Kinematic Viscosity@40°C	32 cSt
Kinematic Viscosity@100°C	5.4 cSt
Viscosity Index	105

SAE Viscosity Grade	10W-30
Kinematic Viscosity@40°C	60 mm²/s
Kinematic Viscosity@100°C	9.4 mm²/s
Viscosity Index	138
Density@15°C	882 kg/m³

ISO Fluid Type	HV
Kinematic Viscosity@-4°F	2630 cSt
Kinematic Viscosity@104°F	46 cSt
Kinematic Viscosity@212°F	7.9 cSt
Viscosity Index	143

ISO Fluid Type	HV
Kinematic Viscosity@-4°F	1430 cSt
Kinematic Viscosity@104°F	32 cSt
Kinematic Viscosity@212°F	6.1 cSt
Viscosity Index	143

ISO Viscocity Grade	32
ISO Fluid Type	HM
Kinematic Viscosity@0°C	324 cSt
Kinematic Viscosity@40°C	32 cSt
Kinematic Viscosity@100°C	5.5 cSt
