Filters
Within Plant & Agriculture, Filters covers the engine, hydraulic, and equipment-system filters fitted to plant equipment, agricultural tractors, telehandlers, commercial vehicles, and the wider plant-and-vehicle filtration aftermarket — covering engine air filters (intake-air filtration, in panel and round-canister formats), engine oil filters (in spin-on, cartridge, and centrifugal-bypass formats), fuel filters (primary water-separator and secondary fine-fuel filters for diesel engines; in-line and cartridge formats), hydraulic filters (return-line, pressure-line, and suction-line filters for hydraulic-circuit cleanliness), cab air filters (for operator-cab HVAC systems — particle and activated-carbon filtration), and the matching filter housings, sealing rings, and service hardware.
Parts for Machines supplies filters across the plant, agricultural, and commercial-vehicle aftermarket. The category covers both OEM-pattern filters (matched exactly to specific equipment fitments by housing and filter dimensions) and high-quality aftermarket filters from specialist filter manufacturers.
Product pages list the filter type (engine air, oil, fuel, hydraulic, cab-air), the equipment application (the equipment make, model, and engine the filter fits), the OEM cross-reference part number, the filter dimensions (overall diameter, height, sealing-ring size), the filter rating (the smallest particle size filtered — typical 5-30 microns for hydraulic; 10-30 microns for fuel), the filter capacity (how much contamination the filter can hold before reaching pressure-drop limits), the filter media (paper, synthetic, glass-fibre, micro-glass for ultra-fine filtration), and any specific service-life specification.
For replacement of an existing filter, the OEM part number is the most reliable match. Filters have specific dimensional and filtration ratings — wrong-spec substitution gives inadequate filtration (engine wear, hydraulic-circuit contamination) or excessive flow restriction (engine starvation, hydraulic-pump damage). Always specify the OEM-equivalent filter for the equipment. Trade pricing on bulk service-pack orders is available; contact the team via WhatsApp 07754288583.
| Thread Size | 3/4 x 16 UNF |
|---|---|
| Outer Diameter | 80 mm (3.15 inch) |
| Gasket OD | 70 mm (2.76 inch) |
| Gasket ID | 60 mm (2.36 inch) |
| Length | 122 mm (4.80 inch) |
| Outer Diameter | 83.5 mm (3.29 inch) |
|---|---|
| Inner Diameter Top End | 37 mm (1.46 inch) |
| Bottom Hole Diameter | 9.5 mm (0.37 inch) |
|
Length 150.5 mm (5.93 inch)
|
|
| Overall Length | 150.5 mm (5.93 inch) |
| Thread Size | M 20 x 1.5 |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 71.6 mm (2.82 inch) |
| Gasket ID | 62.4 mm (2.46 inch) |
| Length | 85 mm (3.35 inch) |
| Outer Diameter | 72.5 mm (2.85 inch) |
|---|---|
| Inner Diameter | 33.5 mm (1.32 inch) |
| Inner Diameter Bottom End | 33.5 mm (1.32 inch) |
| Length | 135 mm (5.32 inch) |
| Overall Length | 141 mm (5.55 inch) |
| Outer Diameter | 68 mm (2.68 inch) |
|---|---|
| Inner Diameter | 32 mm (1.26 inch) |
| Inner Diameter Bottom End | 32 mm (1.26 inch) |
| Length | 106 mm (4.17inch) |
| Overall Length | 108mm (4.25 inch) |
| Thread Size | 3/4 x 16 UN |
|---|---|
| Outer Diameter | 97 mm (3.88 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 85 mm (3.40 inch) Over |
| Outer Diameter | 80 mm (3.15 inch) |
|---|---|
| Inner Diameter | 13.6 mm (0.54 inch) |
| Inner Diameter Bottom End | 13.6 mm (0.54 inch) |
| Length | 106 mm (4.17 inch) |
| Length | 110 mm (4.33 inch) |
| Thread Size | 1 x 12 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 71 mm (2.80 inch) |
| Gasket ID | 61 mm (2.40 inch) |
| Length | 137 mm (5.39 inch) |
| Thread Size | 3/4 x 16 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.84 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 102 mm (4.02 inch) Over |
| Thread Size | 3/4 x 16 UNF |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 63 mm (2.48 inch) |
| Length | 137 mm (5.39 inch) |
| Thread Size | 3/4 x 16 UN |
|---|---|
| Outer Diameter | 83 mm (3.27 inch) |
| Gasket OD | 63 mm (2.48 inch) |
| Gasket ID | 57 mm (2.24 inch) |
| Length | 101 mm (3.98 inch) |
| Outer Diameter | 100 mm (3.94 inch) |
|---|---|
| Inner Diameter | 71 mm (2.80 inch) |
| Inner Diameter Bottom End | 71 mm (2.80 inch) |
| Length | 79 mm (3.11 inch) |
| Overal Length | 79 mm (3.11 inch) |
| Thread Size | M 16 x 1.5 |
|---|---|
| Outer Diameter | 80 mm (3.15 inch) |
| Gasket OD | 68.5 mm (2.70 inch) |
| Gasket ID | 61.5 mm (2.42 inch) |
| Length | 156 mm (6.14 inch) |
| Thread Size | 13/16 x 16 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 86 mm (3.39 inch) |
| Gasket ID | 77 mm (3.03 inch) |
| Length | 135 mm (5.31 inch) |
| Outer Diameter | 86 mm (3.39 inch) |
|---|---|
| Inner Diameter | 13.5 mm (0.53 inch) |
| Inner Diameter Bottom End | 13.5 mm (0.53 inch) |
| Length | 105 mm (4.13 inch) |
| Overall Length | 110 mm (4.33 inch) |
| Thread Size | 13/16 x 16 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 71 mm (2.80 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 137 mm (5.39 inch) |
| Thread Size | 3/4 x 16 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 102 mm (4.02 inch) |
| Thread Size | M 22 x 1.5 |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 137 mm (5.39 inch) |
| Thread Size | 3/4 x 16 UN |
|---|---|
| Outer Diameter | 97 mm (3.88 inch) |
| Gasket OD | 72.5 mm (2.90 inch) |
| Gasket ID | 62.8 mm (2.51 inch) |
| Length | 137 mm (5.48 inch) |
| Thread Size | 3/4 x 16 UNF |
|---|---|
| Outer Diameter | 80 mm (3.15 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 146 mm (5.75 inch) |
| Thread Size | M 16 x 1.5 |
|---|---|
| Outer Diameter | 80 mm (3.15 inch) |
| Gasket OD | 71 mm (2.80 inch) |
| Gasket ID | 61 mm (2.40 inch) |
| Length | 122 mm (4.80 inch) |
| Outer Diameter | 84 mm (3.31 inch) |
|---|---|
| Inner Diameter | 23.4 mm (0.92 inch) |
| Inner Diameter Bottom End | 23.4 mm (0.92 inch) |
| Length | 130 mm (5.12 inch) |
| Overall Length | 136 mm (5.35 inch) |
| Outer Diameter | 83 mm (3.27 inch) |
|---|---|
| Inner Diameter | 36 mm (1.42 inch) |
| Inner Diameter | Bottom End 36 mm (1.42 inch) |
| Length | 169 mm (6.65 inch) |
| Overall Length | 169 mm (6.65 inch) |
| Outer Diameter | 96 mm (3.78 inch) |
|---|---|
| Inner Diameter | 13.5 mm (0.53 inch) |
| Inner Diameter Bottom End | 13.5 mm (0.53 inch) |
| Length | 105 mm (4.13 inch) |
| Overall Length | 110 mm (4.33 inch) |
| Outer Diameter | 68 mm (2.68 inch) |
|---|---|
| Inner Diameter | 32 mm (1.26 inch) |
| Inner Diameter Bottom End | 32 mm (1.26 inch) |
| Length | 155 mm (6.10 inch) |
| Overall Length | 156 mm (6.14 inch) |
| Outer Diameter | 72.5 mm (2.85 inch) |
|---|---|
| Inner Diameter | 11.5 mm (0.45 inch) |
| Inner Diameter Bottom End | 11.5 mm (0.45 inch) |
| Length | 60.5 mm (2.38 inch) |
| Overall Length | 60.5 mm (2.38 inch) |
| Thread Size | 3/4 x 16 UN |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 62 mm (2.44 inch) |
| Length | 95 mm (3.74 inch) |
| Thread Size | 3/4 x 16 UNF |
|---|---|
| Outer Diameter | 97 mm (3.82 inch) |
| Gasket OD | 72 mm (2.83 inch) |
| Gasket ID | 63 mm (2.48 inch) |
| Length | 137 mm (5.39 inch) |
| Length | 400 mm (15.75 inch) |
|---|---|
| Width | 180 mm (7.09 inch) |
| Height | 40 mm (1.57 inch) |
| Overall Height | 40 mm (1.57 inch) |
| Efficiency | Beta 1000 99.9% |
| Thread Size | 3/4 x 16 UN |
|---|---|
| Outer Diameter | 77 mm (3.03 inch) |
| Gasket OD | 70 mm (2.76 inch) |
| Gasket ID | 60 mm (2.36 inch) |
| Length | 123 mm (4.84 inch) |
