Three measurements identify a rubber track: track width (in mm — the working surface width), pitch (the centre-to-centre distance between the lugs on the inside surface, typically 72.5mm or 100mm), and link count (the number of lug-and-bar segments around the track). Take all three measurements from the existing track. Alternatively — and faster — search by the OEM equipment model number (the model identifies the track size fitted from the factory). For older equipment or unusual variants, WhatsApp 07754288583 with the equipment model and serial number for cross-reference.

Replace both tracks at the same time wherever possible — track wear is normally roughly even on both sides, and a new track running against a worn track creates uneven wear, drive-mechanism stress, and shorter lifespan on the new track. The exception is when one track has failed early due to a specific damage event (a cut, a bead failure) while the other is in good condition — in that case, replacing the damaged track and assessing the other for wear is reasonable, but expect to replace the second track sooner rather than later.

Standard rubber tracks have a black natural-rubber compound that leaves marks on paved surfaces (tarmac, concrete, polished floors) — fine for construction, agricultural, and outdoor applications. Non-marking tracks use a white or grey synthetic rubber compound that doesn't leave marks — used for indoor work (warehouse, manufacturing-plant maintenance), paved-surface work (urban construction), and applications where surface damage or marking is unacceptable. Non-marking tracks are typically slightly more expensive and have similar wear characteristics to standard tracks.

Rubber track life depends heavily on the operating surface, operator habits, and machine maintenance. As rough guidance: 1500-2500 hours of working life is typical for a rubber track on mixed surfaces; abrasive surfaces (gravel, demolition rubble) shorten this; soft surfaces (soil, lawn, gentle landscaping) extend it. Check tracks for cuts, exposed steel cords, missing lugs, and bead wear regularly — replace before the steel cords become exposed or the bead pattern is worn flat. Operating with a damaged track risks track failure during work.

Returns are accepted within 30 days of purchase, in original packaging, on orders delivered within the United Kingdom. For damaged-on-arrival items, report within 24 hours with photographs to [email protected] — we will typically arrange collection and replacement at no cost to you. For parts that don't fit your machine, the Fit Guarantee covers a hassle-free return at no cost. For buyer's remorse — you've changed your mind or ordered the wrong item, email us first to obtain a Return Merchandise Number; a restocking fee may apply. Refunds are issued to the original payment method once the return is inspected.

Delivery time depends on the product, your destination, and availability — the estimated time for any item appears on the product page, and 'Check where we deliver' confirms coverage for your postcode before you order. Next-day delivery is available on most products; the option appears at checkout when applicable. We deliver across the UK, Europe, the Middle East, and Africa. Use the country selector at checkout to confirm coverage and delivery options for your destination.

Clear

Rubber Track

Filters

View as

Within Under Carriage, Rubber Track is the highest-volume sub-section — covering the rubber tracks fitted to mini-excavators, midi-excavators, compact track loaders, telehandlers (some configurations), and the tracked-undercarriage compact plant equipment used in construction, landscaping, agricultural, and rental fleet applications. Parts For Machines supplies replacement rubber tracks for trade and fleet use.

Rubber tracks differ from the steel tracks fitted to larger excavators (covered separately under the parent Under Carriage section). They run on rubber-tyred rollers, are quieter and gentler on hard surfaces (tarmac, paved areas, lawns), and are the standard for most compact and mini plant equipment up to roughly 8 tonnes operating weight.

Track identification depends on three measurements: the track width (in mm — typical mini-excavator tracks run 230mm, 250mm, 300mm, 320mm, 350mm, 400mm, 450mm, 500mm), the pitch (the centre-to-centre distance between the lugs on the inside of the track — typically 72.5mm or 100mm), and the link count (the number of lug-and-bar segments around the track — varies by track length, typically 39-86 links for mini-excavator tracks). All three measurements must match the original track for correct fit. Parts For Machines cross-references rubber tracks by these three dimensions and by the OEM-equipment model (Kubota mini-excavators, Takeuchi mini-excavators, Hitachi mini-excavators, Doosan mini-excavators, JCB mini-excavators, etc. — the model code identifies the track size used by that equipment from the factory).

Product pages list track width, pitch, link count, the OEM equipment models the track fits, and any directional-tread or non-marking variants (non-marking tracks are sometimes specified for paved-surface and indoor applications). Contact the team via WhatsApp 07754288583 with the equipment model number for cross-reference, or with the existing track's three measurements (width × pitch × link count) for direct match.
