Product Number: OSMHD300-B
Variations
Rated at a maximum load of 300 kg with 25 mm deflection, OSMHD300-B is an open spring mounting built for demanding high-load and shock-duty installations where conventional mounts would be overstressed. With an overall height of 128 mm (dimension E), a base diameter of 86 mm (dimension D), and an M12 threaded connection, this Type B mount occupies a well-defined footprint while delivering the high-deflection, low-natural-frequency isolation characteristic of the open spring design. Rubber-to-metal bonded construction combines a steel spring carrier with bonded rubber elements that may be loaded in shear, compression, or a combination of both. This construction reduces transmitted vibration, protects surrounding structures from fatigue, and extends machinery service life. The open-frame format allows visual inspection of the spring element without dismantling, a practical advantage in scheduled-maintenance environments. At 69 mm across the mount face (dimension A) and 113 mm for dimension B, with a centring flange dimension CF of 96 mm and a fixing slot of 11×20 mm, OSMHD300-B sits in the upper range of the open spring mounting series, suited to heavy plant, power generation sets, marine auxiliary machinery, railway and mass-transit equipment, and military and defence platforms where load and shock inputs are substantial. Agricultural and construction machinery operating in off-highway conditions also represent typical deployment contexts. Custom variants in stainless steel or oil-resistant and high-temperature rubber compounds are available on request.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Type | B |
|---|---|
| Overall length / diameter A (mm) | 69 |
| Width / dimension B (mm) | 113 |
| Height / dimension C (mm) | M12 |
| Across flats / clearance CF (mm) | 96 |
| Outer diameter D (mm) | 86 |
| Dimension E (mm) | 128 |
| Fixing hole / dimension F (mm) | 11x20 |
| Max load (kg) | 300 |
| Deflection (mm) | 25 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | OSMHD100-C | OSMHD125-C | OSMHD150-C | OSMHD200-C | OSMHD250-C |
| Type | Spring Mount | Spring Mount | Spring Mount | Spring Mount | Spring Mount |
| Size | 69mm | 69mm | 69mm | 69mm | 69mm |
| Deflection | 25 | 25 | 25 | 25 | 25 |
| Size Range | 51-100mm | 51-100mm | 51-100mm | 51-100mm | 51-100mm |
A. OSMHD300-B is rated to a maximum load of 300 kg with a deflection of 25 mm, placing it in the upper range of the open spring mounting series and making it suitable for heavy-load and shock-duty applications.
A. The mount has a face diameter (A) of 69 mm, dimension B of 113 mm, an M12 threaded connection (C), centring flange CF of 96 mm, base diameter (D) of 86 mm, overall height (E) of 128 mm, and a fixing slot (F) of 11×20 mm. It is a Type B configuration.
A. OSMHD300-B may be loaded in shear, compression, or a combination of both, providing flexibility in mounting orientation and installation design.
A. Open spring mountings in this series are used across construction and off-highway, agriculture, power generation, marine, railway and mass transit, automotive, military and defence applications — wherever high deflection and low natural frequency isolation are required.
A. Yes. Stainless steel metal components and oil-resistant or high-temperature rubber compounds are available on request, as are additional and custom sizes.
A. Related variants include OSM100-A, OSM100-B, OSM100-C, OSM125-B, OSM125-C, OSM15-A, OSM15-B and OSM15-C. Each covers a different load and deflection band to suit the specific application requirement.
A. Every product comes with a different guarantee and warranty. Warranty details are shown in the product tech specs or datasheet where available.
A. Yes — WhatsApp us on 07754 288583 with any questions about specifications, suitability, or compatibility.
