Product Number: IOS40624042
| IOS Bush (Click a part number to navigate to the product page) | ||||
| Part Number | Inner Diameter (A) | Outer Diameter (B) | Rubber Body Length (C) | Overall Length (D) |
|---|---|---|---|---|
| IOS25506568 | 25 | 50 | 65 | 68 |
| IOS1005 | 28.58 | 54.6 | 114 | 123.8 |
| IOS15.5553016 | 15.5 | 55 | 30 | 16 |
| IOS0989 | 28.57 | 57.15 | 85.73 | 88.9 |
| IOS30606068 | 30 | 60 | 60 | 68 |
| IOS36626571 | 36 | 62 | 65 | 71 |
| IOS30637266 | 30 | 63 | 72 | 66 |
| IOS38648088 | 38 | 64 | 80 | 88 |
| IOS30656070 | 30 | 65 | 60 | 70 |
| IOS40658088 | 40 | 65 | 80 | 88 |
Sitting at the largest end of the IOS range, the Inner-Outer-Sleeve Bush IOS40624042 measures 40 mm (A) inner diameter, 62 mm (B) outer diameter, 40 mm (C) length, and 40 mm bore with a 42 mm (D) eccentric dimension, a configuration designed for mainstream general-machinery mounting at moderate dynamic loads where robust deflection control and extended service life matter most. The IOS bush uses rubber-to-metal bonded construction, with vulcanised rubber bonded between precision inner and outer metal sleeves. This bonded assembly delivers high durability under dynamic loads without any requirement for lubrication, making it genuinely maintenance free throughout its working life. The design accommodates loading in shear, compression, or a combination of both, protecting surrounding structures and improving operator comfort in the equipment it serves. At 40 mm inner diameter and 62 mm outer diameter, this is the largest standard geometry in the IOS range and is suited to applications including cab mounts, engine mounts, pivot bearings, and mechanical linkages across construction and off-highway plant, agricultural machinery, power generation equipment, marine installations, and railway and mass transit systems. Military and defence applications are also within scope. The rubber-to-metal bond improves machinery lifespan while absorbing shock and vibration at the mounting interface. This bush is part of a broad IOS family available across a range of inner diameters and lengths. Related sizes include IOS08192830, IOS0877, IOS0989, IOS1004, IOS1005, IOS10222420, IOS10252025, and IOS10273840. Custom sizes, stainless steel metal components, oil-resistant rubbers, and high-temperature rubber compounds are available on request.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Inner Diameter (ØA) | 40mm |
|---|---|
| Outer Diameter (ØB) | 62mm |
| Rubber Body Length (C) | 40mm |
| Overall Length (D) | 42mm |
| Warranty | 6 Months |
| Product Dimension (Right-click the image to expand in a new tab) |
|---|
|
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Suspension Bush - Inner Dia 40mm, Outer Dia 62mm, L 40mm - IOS40624042
|
Open Now |
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||||||||||||
| Technical Specification | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | TB25-60 | TB12-40 | TB12-60 | TB45-45 | TB45-60 | TB50-60 | TB50-75 | TB65-60 | TB75 | TBCBA20-75 | TBCBA24 | SB1316 | SB2166 | SB2201 | SB2106 |
| Type | Bush | Bush | Bush | Bush | Bush | Bush | Bush | Bush | Bush | Bush | Bush | Bush | Bush | Bush | Bush |
| Size | 17.5mm | 27.2mm | 27.2mm | 25mm | 25mm | 35mm | 35mm | 44mm | 50.8mm | 36.8mm | 38.1mm | 25.4mm | 25.4mm | 25.4mm | 28.6mm |
| Deflection | 0.7 | 1.4 | 1.4 | 1.2 | 1.2 | 1.6 | 1.6 | 2 | 2.16 | 2.5 | 2.5 | ||||
| Overall Height | 17.5mm | 27.2mm | 27.2mm | 25mm | 25mm | 35mm | 35mm | 44mm | 50.8mm | 36.8mm | 38.1mm | ||||
| Size Range | 11-25mm | 26-50mm | 26-50mm | 11-25mm | 11-25mm | 26-50mm | 26-50mm | 26-50mm | 51-100mm | 26-50mm | 26-50mm | 26-50mm | 26-50mm | 26-50mm | 26-50mm |
A. The IOS40624042 has an inner diameter (A) of 40 mm, an outer diameter (B) of 62 mm, a length (C) of 40 mm, and an eccentric dimension (D) of 42 mm.
A. No. The rubber-to-metal bonded construction means the IOS40624042 requires no lubrication and is maintenance free throughout its service life.
A. The IOS bush may be loaded in shear, compression, or a combination of both, making it adaptable to a wide range of mounting configurations and dynamic load conditions.
A. Applications include cab mounts, engine mounts, pivot bearings, and mechanical linkages. Industries served include construction and off-highway, agriculture, power generation, marine, railway and mass transit, automotive, and military and defence.
A. IOS40624042 is the largest standard size in the IOS inner-outer-sleeve bush family, suited to mainstream general-machinery mounting at moderate dynamic loads.
A. Yes. Stainless steel metal components, oil-resistant rubbers, high-temperature rubber compounds, and additional custom sizes are available on request.
A. We accept all major credit and debit cards, along with PayPal.
A. Standard UK mainland delivery is 3–5 working days. Next-day delivery is available on most products and will appear as an option at checkout where eligible.
