Product Number: SB2201
| Spherical Bush (Click a part number to navigate to the product page) | |||||
| Part Number | Inner Diameter (A) | Outer Diameter (B) | Rubber Body Length (C) | Overall Length (D) | Axial Load Capacity (Pz) |
|---|---|---|---|---|---|
| SB1316 | 25.4 | 66.7 | 48 | 54.2 | 34 |
| SB2166 | 25.4 | 66.8 | 47.6 | 54.2 | 34 |
| SB2201 | 25.4 | 66.7 | 47.6 | 54 | 34 |
| SB2106 | 28.6 | 90.5 | 70 | 76.2 | 58 |
| SB1285 | 38.1 | 104.8 | 76.2 | 82.6 | 80 |
Carrying a rated axial load of 34.0 kN, the SB2201 is a 25.4 mm bore spherical bush designed to perform across demanding dynamic-load applications where maintenance access is limited or impractical. Rubber bonded between inner and outer metal sleeves, this mid-range unit delivers reliable performance under sustained service without any lubrication requirement. The rubber-to-metal bonded construction is engineered to absorb and dissipate energy under dynamic loading in shear, compression, or combined directions. Freedom from lubrication reduces service intervals and extends component life, while the bonded assembly protects surrounding structures and improves operator comfort in cab and vehicle installations. Custom configurations in stainless steel metals and oil-resistant or high-temperature rubbers are available on request. With a bore diameter (A) of 25.4 mm, outer diameter (B) of 66.7 mm, sleeve length (C) of 47.6 mm, outer sleeve diameter (D) of 54.0 mm, and an axial load rating (Pz) of 34.0 kN, the SB2201 suits pivot bearings, mechanical linkages, and cab mounts in construction and off-highway equipment, as well as agricultural machinery, power generation plant, marine installations, and railway and mass transit applications where its mid-range load capacity aligns with the demands of the installation. The spherical bush range extends across multiple bore sizes and load bands. Related variants include SB1285, SB1316, SB2106, and SB2166, each suited to different dimensional and load requirements, refer to the individual listings for full specifications. The SB2201 is supplied as a single assembled bush unit. No warranty information is available for this product.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Inner Diameter (A) | 25.4 mm |
|---|---|
| Outer Diameter (B) | 66.7 mm |
| Rubber Body Length (C) | 47.6 mm |
| Overall Length (D) | 54 mm |
| Axial Load Capacity (Pz) | 34 kN |
| Warranty | 6 months |
| Product Dimension (Right-click the image to expand in a new tab) |
|---|
|
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Suspension Bush - Inner Dia 25.4mm, Outer Dia 66.7mm, L 47.6mm - SB2201
|
Open Now |
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | ECC1165-45 | ECC1165-45-45 | ECC1165-60 | ECC1165-60-60 | IOS0877 |
| Type | Bush | Bush | Bush | Bush | Bush |
| Size | 25.4mm | 25.4mm | 25.4mm | 25.4mm | 25.4mm |
| Size Range | 26-50mm | 26-50mm | 26-50mm | 26-50mm | 26-50mm |
A. The SB2201 has a bore diameter (A) of 25.4 mm, outer diameter (B) of 66.7 mm, sleeve length (C) of 47.6 mm, and an outer sleeve diameter (D) of 54.0 mm.
A. The SB2201 carries a rated axial load (Pz) of 34.0 kN, placing it in the mid-range of the spherical bush family.
A. No. The rubber-to-metal bonded construction is maintenance free and requires no lubrication throughout its service life.
A. The SB2201 may be loaded in shear, compression, or a combination of both, depending on the application.
A. The SB2201 is suited to pivot bearings, mechanical linkages, and cab mounts across construction and off-highway, agriculture, power generation, marine, railway and mass transit, automotive, and military and defence applications.
A. Yes. Stainless steel metal components and oil-resistant or high-temperature rubber compounds, as well as additional and custom sizes, are available on request.
A. Related variants include SB1285, SB1316, SB2106, and SB2166. Each covers different dimensional and load requirements — refer to the individual product listings for full specifications.
