Within Wood Working, Table Saw covers the bench-and-cabinet-mounted table saws used in workshop and site work for ripping, cross-cutting, and panel-cutting work — covering portable site table saws (compact, transportable, for site-based cutting), contractor-pattern table saws (mid-weight, mid-power, suited to fixed workshop use), and cabinet table saws (heavy-duty, fixed-installation, for trade workshop and joinery use).
Parts for Machines supplies table saws across the trade and professional ranges, with rated cutting capacities typically running from 250mm blade diameter (compact site saws with cutting depths up to 80mm) up to 315mm and above (heavier contractor and cabinet saws with cutting depths up to 100mm+).
Product pages list the blade diameter (typical 250mm, 254mm, 315mm), the maximum cutting depth at 90 degrees and at 45 degrees (bevel cuts reduce maximum depth), the rip-fence capacity (the maximum width that can be ripped from the blade — typical 600-800mm on site saws; up to 1,200mm+ on cabinet saws with rip-fence extensions), the motor power (typical 1.5-2.0 kW for site saws; 2.0-3.0 kW for cabinet saws), the power source (110V or 230V single-phase for site and contractor saws; 400V three-phase on the largest cabinet saws), the no-load blade speed (typical 3,000-4,500 RPM), the dust-extraction port size, and the safety features (riving knife, blade guard, NVR no-volt-release switch).
For workshop use, 230V is standard. Trade pricing on multi-tool orders is available; contact the team via WhatsApp 07754288583.
| Input Supply | 230v (13A) |
|---|---|
| Motor Power | 2.2kW (3hp) |
| Blade Tilting | 45° left |
| Depth of Cut | 80mm @ 90° / 65mm @ 45° |
| Standard Table Size | 635mm x 420mm (LxW) |
| ITEM NO | 01332 |
|---|---|
| Input Supply | 230v (16A) |
| Motor Power | 2.2kW (3hp) |
| Blade Tilting | to left 45° |
| Depth of Cut @ 45° | 53mm |
| ITEM NO | 01446 |
|---|---|
| Input Supply | 230v (16A) |
| Motor Power | 3kW (4hp) |
| Blade Tilting | to left 45° |
| Depth of Cut @ 45° | 80mm |
| ITEM NO | 01986 |
|---|---|
| Input Supply | 230v (13A) |
| Motor Power | 1.8kW (2.4hp) |
| Extended Table Size | 940mm x 640mm |
| Depth of Cut @ 45° | 65mm |
| ITEM NO | 01513 |
|---|---|
| Input Supply | 230v (13A) |
| Power Cable | 2mtr |
| Motor Power | 1200w (Saw) / 1000w (Extractor) |
| Depth of Cut | 40mm @ 90° / 24mm @ 45° |
