Product Number: SB2166
Variations
| Spherical Bush (Click a part number to navigate to the product page) | |||||
| Part Number | Inner Diameter (A) | Outer Diameter (B) | Rubber Body Length (C) | Overall Length (D) | Axial Load Capacity (Pz) |
|---|---|---|---|---|---|
| SB1316 | 25.4 | 66.7 | 48 | 54.2 | 34 |
| SB2166 | 25.4 | 66.8 | 47.6 | 54.2 | 34 |
| SB2201 | 25.4 | 66.7 | 47.6 | 54 | 34 |
| SB2106 | 28.6 | 90.5 | 70 | 76.2 | 58 |
| SB1285 | 38.1 | 104.8 | 76.2 | 82.6 | 80 |
The SB2166 is a 25.4 mm bore spherical bush engineered for dynamic load control where pivot bearings and mechanical linkages demand a reliable, maintenance-free solution. Built on a rubber-bonded inner-outer-sleeve construction, it is designed to carry loads in shear, compression, or a combination of both, making it well suited to applications that impose variable force directions during service. At the core of the SB2166 design is a rubber-to-metal bonded construction that requires no lubrication throughout its service life. The rubber layer absorbs and damps dynamic loads, protecting surrounding structures and improving operator comfort, while the metal sleeves provide the structural integrity needed for prolonged operation under demanding conditions. This combination promotes extended machinery lifespan without the maintenance overhead associated with conventional lubricated bushes. With principal dimensions of 25.4 mm bore (A), 66.8 mm outer length (B), 47.6 mm outer diameter (C), 54.2 mm inner sleeve length (D), and a rated static load Pz of 34.0 kN, the SB2166 occupies the lower end of the spherical bush load range, well matched to applications where modest load capacity and controlled deflection are the governing requirements. Typical service environments include cab mounts, off-road vehicle pivot joints, construction and agricultural machinery linkages, and power generation and marine installations. The SB2166 forms part of a broader spherical bush range. Complementary sizes are available as SB1285, SB1316, SB2106, and SB2201, each offering different bore and load characteristics to suit wider programme requirements. The SB2166 is supplied as a single bush unit.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Inner Diameter (A) | 25.4 mm |
|---|---|
| Outer Diameter (B) | 66.8 mm |
| Rubber Body Length (C) | 47.6 mm |
| Overall Length (D) | 54.2 mm |
| Axial Load Capacity (Pz) | 34 kN |
| Warranty | 6 months |
| Product Dimension (Right-click the image to expand in a new tab) |
|---|
|
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Suspension Bush - Inner Dia 25.4mm, Outer Dia 66.8mm, L 47.6mm - SB2166
|
Open Now |
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | ECC1165-45 | ECC1165-60 | IOS0877 | ECC1165-60-60 | ECC1165-45-45 |
| Type | Bush | Bush | Bush | Bush | Bush |
| Size | 25.4mm | 25.4mm | 25.4mm | 25.4mm | 25.4mm |
| Size Range | 26-50mm | 26-50mm | 26-50mm | 26-50mm | 26-50mm |
A. The SB2166 has a bore (A) of 25.4 mm, outer length (B) of 66.8 mm, outer diameter (C) of 47.6 mm, inner sleeve length (D) of 54.2 mm, and a rated static load (Pz) of 34.0 kN.
A. The SB2166 carries a static load rating (Pz) of 34.0 kN, positioning it in the lower band of the spherical bush range and making it appropriate for lighter-duty pivot and linkage applications where modest load and controlled deflection are required.
A. No. The rubber-to-metal bonded construction of the SB2166 is entirely maintenance free and requires no lubrication throughout its service life.
A. The SB2166 may be loaded in shear, compression, or a combination of both, giving flexibility in how it is integrated into pivot bearings, mechanical linkages, and cab mount assemblies.
A. The SB2166 is suited to construction and off-highway equipment, agricultural machinery, power generation, marine installations, automotive pivot joints, and railway and mass transit applications, as well as military and defence uses.
A. Yes. The spherical bush range includes SB1285, SB1316, SB2106, and SB2201, each with different bore dimensions and load ratings to suit wider programme or replacement requirements.
A. Yes. Stainless steel metalwork, oil-resistant rubber, and high-temperature rubber compounds are available on request, as are additional and custom sizes.
