Product Number: GDM200F/VS
Variations
When drilling plastics, non-ferrous metals, or fine-tolerance work, fixed-step speed changes often aren't precise enough. The Sealey GDM200F/VS variable speed floor pillar drill solves this by offering stepless speed control from 150 to 2300rpm so you can dial in exactly the right speed for the job, not simply the nearest available setting. Speed is adjusted via a centre idle pulley controlled by a lever, which varies the effective diameter of two spring-tensioned cone pulleys in the belt transmission. This design delivers smooth, consistent speed adjustment across the full range. The machine is built on the same 1630mm-height floor-standing frame as the GDM200F, with an 80mm column diameter, 80mm spindle travel, and a 16mm (5/8") MT2 chuck capacity. Motor power is 450W with an input power of 650W. Spindle centre to column is 178mm. Safety features include a no-volt release switch, allowing insurance company approval for use in educational establishments. A chuck guard is supplied as standard. A mortise attachment is available separately (Model No. MA10). Base size is 460 x 275mm. Maximum spindle to table distance is 730mm. Maximum spindle to base is 1170mm. Weight is 71kg extra assistance must be provided at the delivery point to assist with safe delivery. The optional GDMX/KC keyless chuck (16mm) is available as an accessory.
Key Features:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Model No | GDM200F/VS |
|---|---|
| Base Size | 460 x 275mm |
| Brand | Sealey |
| Collar Diameter | Ø60mm |
| Column Diameter | Ø80mm |
| Drilling Capacity (Chuck Size) | 16mm |
| Maximum Distance Spindle to Base | 1170mm |
| Maximum Distance Spindle to Table | 730mm |
| Motor Power (Start) | 450W(650W) |
| Nett Weight | 71kg |
| Number of Speeds | Variable |
| Optional Accessories | GDMX/KC - Keyless Pillar Drill Chuck 16mm |
| Overall Height | 1630mm |
| Speed Range | 150-2300rpm |
| Spindle Centre to Column | 178mm |
| Spindle Nose Taper | MT2 |
| Spindle Travel | 80mm |
| Supply | 230V |
| Swing | 356mm |
| Working Base Surface Size | 200 x 220mm |
| Working Table Surface Size | Ø310mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: UK Mainland Free
Next Day Delivery Available
Delivery Estimate: 2 to 4 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
Sealey GDM140F Floor Pillar Drill 12-Speed 370W 1500mm
£368.12
£360.90
2% OFF
Free delivery in UK Mainland
|
Sealey GDM150B 16-Speed Bench Pillar Drill 1070mm 650W 230V
£466.57
£457.42
2% OFF
Free delivery in UK Mainland
|
Sealey GDM160F Floor Pillar Drill 16-Speed 550W 230V
£464.40
£455.29
2% OFF
Free delivery in UK Mainland
|
Draper 95092 16 Speed Heavy Duty Floor Standing Drill, 650W
£599.57
£587.81
2% OFF
Free delivery in UK Mainland
|
Draper 95314 16 Speed Heavy Duty Bench Drill, 650W
£493.99
£484.30
2% OFF
Free delivery in UK Mainland
|
Draper 2019 16 Speed Floor Standing Drill, 1100W
£471.20
£461.96
2% OFF
Free delivery in UK Mainland
|
|||
| Technical Specification | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | GDM140F | GDM150B | GDM160F | DPG30 | 95092 | DPG99 | 95314 | 02016 | 02019 |
A. The GDM200F/VS offers variable, stepless speed control between 150 and 2300rpm. Rather than selecting from fixed speeds, you can adjust continuously to precisely the speed required for your material and bit, using a speed adjustment lever that moves a centre idle pulley between two spring-tensioned cone pulleys.
A. The speed range is continuously variable from 150 to 2300rpm.
A. It is fitted with a 16mm (5/8") capacity chuck with a No. 2 Morse Taper (2MT) spindle.
A. Yes. Safety devices include a no-volt release switch, which allows insurance company approval for use in educational establishments.
A. Overall height is 1630mm. Base size is 460 x 275mm. Column diameter is 80mm. Spindle travel is 80mm. Maximum spindle to table distance is 730mm. Maximum spindle to base is 1170mm. Spindle centre to column is 178mm.
A. The GDM200F/VS weighs 71kg. It is a heavy item and extra assistance must be provided at the delivery point to help with its safe delivery.
A. Yes. The GDM200F is the equivalent model in the same product family with 16 fixed speeds (120-3000rpm) rather than variable speed. Please check the GDM200F listing for its full specification.
A. Alternative pillar drills serving a similar function include the GDM120B, GDM140F, GDM150B, and GDM160F. Please check individual listings to compare specifications.
A. Yes. The optional GDMX/KC keyless pillar drill chuck (16mm) is available as an accessory.
A. Standard UK mainland delivery is 3-5 working days.
