Product Number: E3
Variations
Where a strut end simply needs to hinge on a pin, an eye fitting is the most direct connection. The Metrol E3 is a steel eye end fitting with an M6 thread, a 22mm body and a 8.5mm eye hole. It screws onto the strut rod and pins through its eye to a mounting point, forming a hinged joint that opens and closes with the panel. Its M6 thread suits a gas strut with a 6 & 8mm rod, and the eye pins to pin-stud brackets such as BRK-4B, BRK-7B, BRK-8-90. It measures 15mm across the eye boss, on a 9mm shoulder, with a 4.8mm section. Like every end fitting in the range it transfers the strut's force to the structure: a ball joint gives a connection that swivels in any direction, an eye a single-axis hinge, a clevis fork an in-line pinned joint, and a rose eye absorbs slight misalignment. It threads onto a gas strut with a 6 & 8mm rod, and is chosen by matching the thread to the strut and the size to the space behind the mounting. Typical applications include fold-down benches, worktop flaps, toolbox lids, seat bases. Within the M6 eye range, its nearest sizes are E2 and E4, differing by body length; a 316 stainless version is available as SSE3.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Material | Steel |
|---|---|
| Female Thread (A) | M6 |
| Fitting Length (B) | 22mm |
| Outer Radius (C) | 15mm |
| Eye Hole Diameter (D) | 8.5mm |
| Shoulder Width (E) | 9mm |
| Thickness (F) | 4.8mm |
| Shoulder Height (G) | 12mm |
| Gas Strut Rod Diameter | 6 & 8mm |
E full range End Fittings.pdf
|
Open Now |
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | E9 | E8 | E7 | E6 | SSE9 |
A. Match the M6 thread to your strut rod and pick the body length you need; this one is 22mm.
A. A gas strut with a 6 & 8mm rod.
A. Pin-stud brackets such as BRK-4B, BRK-7B, BRK-8-90.
A. Yes, SSE3.
A. Yes — the E3 is a genuine Metrol product, available from PartsForMachines.
A. Every product comes with a different guarantee and warranty. Warranty details are shown in the product’s tech specs or datasheet where available.
