Product Number: E6
Variations
Where a strut end simply needs to hinge on a pin, an eye fitting is the most direct connection. The Metrol E6 is a steel eye end fitting with an M8 thread, a 18mm body and a 8mm eye hole. Threaded onto the rod, its eye accepts a pin at the mounting so the strut can swing as the panel is raised and lowered. Its M8 thread suits a gas strut with a 10mm rod, and the eye pins to pin-stud brackets such as BRK-4B, BRK-7B, BRK-8-90. It measures 18mm across the eye boss, on a 18mm shoulder, with a 9.8mm section. It is one of a family of end fittings that connect a strut to its mounting — a ball joint to swivel freely, an eye to hinge on a pin, a clevis to pin in line, or a rose eye to take up misalignment. Sized for a 10mm rod, the fitting is matched by thread to the strut and by size to the fixing. It is found on display lids, counter hatches, canopy panels, loft hatches and similar panels. Within the M8 eye range, its nearest sizes are E7, differing by body length; a 316 stainless version is available as SSE6.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Material | Steel |
|---|---|
| Female Thread (A) | M8 |
| Fitting Length (B) | 18mm |
| Outer Radius (C) | 18mm |
| Eye Hole Diameter (D) | 8mm |
| Shoulder Width (E) | 18mm |
| Thickness (F) | 9.8mm |
| Shoulder Height (G) | 6mm |
| Gas Strut Rod Diameter | 10mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
E full range End Fittings.pdf
|
Open Now |
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | E5 | E4 | E3 | E2 | E1 |
A. Match the M8 thread to your strut rod and pick the body length you need; this one is 18mm.
A. A gas strut with a 10mm rod.
A. Pin-stud brackets such as BRK-4B, BRK-7B, BRK-8-90.
A. Yes, SSE6.
A. Yes — the E6 is a genuine Metrol product, available from PartsForMachines.
A. Every product comes with a different guarantee and warranty. Warranty details are shown in the product’s tech specs or datasheet where available.
A. Next-day delivery is available on most products and will appear as an option at checkout where eligible.
