Product Number: FM600-60
Carrying a maximum load of 750 kg with a controlled deflection of 17.0 mm, the FM600-60 is the largest flanged mount in the FM600 series, a 60 Shore A medium-hardness unit dimensioned at 100 mm (A) × 160 mm (D) × 200 mm (E), with an M16 fixing thread and four fixing holes. Where heavier plant demands both reliable structural support and meaningful vibration attenuation in the same mounting point, this grade delivers the broad middle ground: neither sacrificing load capacity for isolation nor stiffness for compliance. Construction follows rubber-to-metal bonded principles throughout, with the rubber element capable of accepting load in shear, compression, or a combination of both. The 60 Shore A compound represents the general-purpose position in the hardness range, harder grades carry higher loads with less movement, while softer grades trade some capacity for greater deflection and isolation sensitivity. At 750 kg maximum load and 17.0 mm deflection, this mount is suited to applications where significant machinery mass must be controlled without excessive movement under dynamic conditions. Custom configurations, including oil-resistant and high-temperature rubber compounds and stainless steel metalwork, are available on request. The FM600-60 serves industries including construction and off-highway, power generation, marine, agriculture, railway and mass transit, automotive, and military and defence. Typical installation contexts include high-load machinery bases, generator sets, compressor skids, and industrial equipment where shock attenuation and operator comfort are both engineering priorities.
Flanged Mountings give high levels of deflection, providing excellent levels of vibration reduction and shock absorption both in vertical & horizontal planes. The Flange Mounts are a low cost & easy to install product. Stainless Steel metals and Oil Resistant / High Temperature rubbers are available on request.
Applications include:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Fixing Holes | 4 |
|---|---|
| Top Width (A) | 100mm |
| Overall Height (B) | 85mm |
| Thread Size (C) | M16 |
| Inner Circle Dimesnion (D) | 160mm |
| Base Plate Width (E) | 200mm |
| Base Thickness (F) | 4mm |
| Fixing Hole Distance (G) | 14.5mm |
| Max Load (kg) | 750 |
| Deflection (mm) | 15.5 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
Anti-Vibration Mount - Flanged Mount Range, Thread Size M6, Max Load 9 Kg- FM007-60
£14.13
£13.85
2% OFF
|
||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | FM007-60 | FM007-75 | FM100-60 | FM100-75 | FM100260 |
| Type | Flanged Mount | Flanged Mount | Flanged Mount | Flanged Mount | Flanged Mount |
| Height | 20mm | 40mm | |||
| Size | 18x20mm | 68mm | |||
| Deflection | 3 | 6.5 | |||
| Size Range | 51-100mm | ||||
| Thread | M6 | M6 | M10 | M10 | M10 |
A. The FM600-60 has a maximum load rating of 750 kg and a deflection of 17.0 mm.
A. The FM600-60 has the following dimensions: A = 100 mm, B = 85 mm, C = M16 thread, D = 160 mm, E = 200 mm, F = 4 mm, G = 14.5 mm, with 4 fixing holes.
A. 60 Shore A represents the medium hardness grade in the flanged mount range. It offers a balance of vibration isolation and structural support, making it suitable for the broad middle ground of machinery mounting — where loads are substantial but attenuation of vibration and shock is still a priority.
A. The FM600-60 can be loaded in shear, compression, or a combination of both, providing installation flexibility across a range of mounting orientations.
A. The FM600-60 is suited to heavy-load applications across construction and off-highway, power generation, marine, agriculture, railway and mass transit, automotive, and military and defence. Typical uses include generator sets, compressor skids, and industrial machinery bases where both shock attenuation and operator comfort are required.
A. Yes. Stainless steel metalwork and oil-resistant or high-temperature rubber compounds are available on request, along with additional and custom sizes.
A. The FM600 series is available in 40 Shore A (FM600-40) and 75 Shore A (FM600-75), in addition to this 60 Shore A variant. Softer grades provide greater deflection and better isolation at lower loads; harder grades carry higher loads with less movement.
A. Standard UK mainland delivery is 3–5 working days. Next-day delivery is available on most products and will appear as an option at checkout where eligible.
A. We accept returns within 30 days of purchase for items that are unused, undamaged, and in their original packaging. Returns are available only for UK-delivered orders and must include proof of purchase. Before returning an item, please contact us at [email protected] to obtain a Return Merchandise Number (RMN).
