Product Number: RSM242-45-45
Variations
Engineered for sensitive equipment and lower-frequency vibration isolation, this rectangular sandwich mount in 45 Shore A soft-grade rubber offers maximum deflection under load, making it the preferred choice where isolation efficiency matters more than restraint. With a rated load capacity of 450 kg and a deflection rate of 3 mm/kg, the RSM242-45-45 is sized at 168 mm × 57 mm × 43 mm (A × B × C) with additional reference dimensions of D 127 mm, E 146 mm, F 11 mm and G 5 mm. The soft rubber compound is rubber-to-metal bonded, allowing the mount to be loaded in shear, compression or a combination of both. At 45 Shore A, the grade delivers greater deflection per unit of load than harder alternatives, producing the high isolation efficiency suited to instruments, electronics and light equipment where protecting sensitive components from vibration-induced stress is the priority. This construction also improves operator comfort and protects surrounding structures from transmitted vibration. The RSM242-45-45 serves industries including agriculture, marine, power generation and railway and mass transit, as well as construction and off-highway, automotive, and military and defence applications. It is particularly well suited to lightweight, low-load installations where lower-frequency isolation is required. Stainless steel hardware and oil-resistant or high-temperature rubber compounds are available on request, as are additional and custom sizes. This mount is part of a wider family covering alternative Shore grades and footprint sizes. Medium-duty 60 Shore A and firm 70 Shore A variants are listed as RSM242-60 and RSM242-70 respectively.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||||||||
| Technical Specification | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | V3630-55-55 | UU1492-50-50 | UU1479-50-50 | UU1479-40-40 | TMS08100-65-65 | TMS08065-55-55 | RSM242-60-60 | RSM242-70-70 | RSM284-60-60 | RSM284-70-70 | RSM322-60-60 |
| Type | Mounting | Mounting | Mounting | Mounting | Anti-Vibration Mount | Anti-Vibration Mount | Mounting | Mounting | Mounting | Mounting | Mounting |
| Size | 110x57mm | ||||||||||
| Mount Type | W & V Mountings | UU Shear Mountings | UU Shear Mountings | UU Shear Mountings | Turret Mountings | Turret Mountings | Rectangular Sandwich Mountings | Rectangular Sandwich Mountings | Rectangular Sandwich Mountings | Rectangular Sandwich Mountings | Rectangular Sandwich Mountings |
| Thread | M8 | M8 | |||||||||
A. The RSM242-45-45 is rated to carry 450 kg with a deflection rate of 3 mm per kg, providing generous movement under load that is characteristic of its 45 Shore A soft-grade rubber.
A. The principal dimensions are: A 168 mm, B 57 mm, C 43 mm, D 127 mm, E 146 mm, F 11 mm and G 5 mm.
A. Softer grades such as 45 Shore A give greater deflection per unit of load and better vibration isolation efficiency, making them the appropriate choice for sensitive instruments, electronics and light equipment, particularly where lower-frequency isolation is required. Harder grades carry higher loads with less movement but sacrifice isolation performance.
A. The RSM242-45-45 may be loaded in shear, compression or a combination of both, allowing flexibility in mounting orientation to suit the installation.
A. The mount is suited to instruments, electronics and light equipment across a wide range of industries, including agriculture, marine, power generation, railway and mass transit, construction and off-highway, automotive, and military and defence.
A. Yes. Medium-duty 60 Shore A (RSM242-60) and firm 70 Shore A (RSM242-70) variants are available in the same footprint. Larger footprint options are listed under the RSM284 and RSM322 families. Stainless steel hardware, oil-resistant rubber and high-temperature rubber compounds, as well as additional and custom sizes, are available on request.
