Product Number: IOS25507985
Variations
| IOS Bush (Click a part number to navigate to the product page) | ||||
| Part Number | Inner Diameter (A) | Outer Diameter (B) | Rubber Body Length (C) | Overall Length (D) |
|---|---|---|---|---|
| IOS30506066 | 30 | 50 | 60 | 66 |
| IOS25503034 | 25 | 50 | 30 | 34 |
| IOS255 | 25 | 50 | 65 | 68 |
| IOS25508085 | 25 | 50 | 80 | 85 |
| IOS25504045 | 25 | 50 | 40 | 45 |
| IOS25506568 | 25 | 50 | 65 | 68 |
| IOS1005 | 28.58 | 54.6 | 114 | 123.8 |
| IOS15.5553016 | 15.5 | 55 | 30 | 16 |
| IOS0989 | 28.57 | 57.15 | 85.73 | 88.9 |
| IOS30606068 | 30 | 60 | 60 | 68 |
Dimensioned at 25 mm bore (A), 50 mm outer diameter (B), 79 mm inner sleeve length (C) and 85 mm overall length (D), the IOS25507985 is an inner-outer-sleeve bush engineered for mainstream general-machinery mounting at moderate dynamic loads. Rubber is bonded between precision inner and outer metal sleeves to deliver high durability across sustained service cycles in construction equipment, agricultural machinery, power generation plant, marine applications and railway and mass transit systems. The rubber-to-metal bonded construction requires no lubrication and is maintenance free, eliminating scheduled service intervals and reducing whole-life running costs. Because the rubber element can accept loads in shear, compression, or a combination of both, the bush performs reliably across many mounting configurations. This versatile load-handling characteristic makes it well suited to mechanical linkages, pivot bearings, cab mounts and engine mounts where moderate deflection and consistent isolation are required together. Constructed to withstand dynamic loads over prolonged service, the IOS25507985 protects surrounding structures, improves machinery lifespan and contributes to improved operator comfort. Custom configurations are available on request, including stainless steel metalwork and oil-resistant or high-temperature rubber compounds, as well as additional and non-standard sizes. This bush is part of the IOS range of eccentric and spherical inner-outer-sleeve bushes. Further sizes and configurations available include IOS08192830, IOS0877, IOS0989, IOS1004, IOS1005, IOS10222420, IOS10252025 and IOS10273840. This product is supplied as a single bush. No warranty information is available for this item. Manufactured in the United Kingdom.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Inner Diameter (ØA) | 25mm |
|---|---|
| Outer Diameter (ØB) | 50mm |
| Rubber Body Length (C) | 79mm |
| Overall Length (D) | 85mm |
| Warranty | 6 Months |
| Product Dimension (Right-click the image to expand in a new tab) |
|---|
|
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Suspension Bush - Inner Dia 25mm, Outer Dia 50mm, L 79mm - IOS25507985
|
Open Now |
Standard Delivery: £5.49
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | ECC1165-45 | ECC1165-60 | TB45-45 | TB45-60 | ECC1165-45-45 |
| Type | Bush | Bush | Bush | Bush | Bush |
| Size | 25.4mm | 25.4mm | 25mm | 25mm | 25.4mm |
| Deflection | 1.2 | 1.2 | |||
| Overall Height | 25mm | 25mm | |||
| Size Range | 26-50mm | 26-50mm | 11-25mm | 11-25mm | 26-50mm |
A. The IOS25507985 has a 25 mm bore (A), 50 mm outer diameter (B), 79 mm inner sleeve length (C) and 85 mm overall length (D).
A. The bush uses a rubber-to-metal bonded construction, with rubber bonded between inner and outer metal sleeves. This provides high durability under dynamic loads and a prolonged service life.
A. No. The IOS25507985 is maintenance free and requires no lubrication, making it suitable for installations where ongoing servicing is impractical.
A. The bush may be loaded in shear, compression, or a combination of both, giving flexibility across a wide range of mounting and linkage applications.
A. Typical applications include pivot bearings, mechanical linkages, cab mounts and engine mounts. It is used across construction and off-highway, agricultural, power generation, marine, railway and mass transit, automotive, and military and defence sectors.
A. Yes. Stainless steel metalwork and oil-resistant or high-temperature rubber compounds are available on request, as are additional and custom sizes.
A. Yes. Related sizes include IOS08192830, IOS0877, IOS0989, IOS1004, IOS1005, IOS10222420, IOS10252025 and IOS10273840.
A. In-stock orders placed before 14:30 Monday to Friday are usually dispatched the same day.
A. Standard UK mainland delivery is 3–5 working days. Next-day delivery is available on most products and will appear as an option at checkout where eligible.
A. Standard UK mainland delivery is 3–5 working days. Next-day delivery is available on most products and will appear as an option at checkout where eligible.
