Product Number: 02-057
The CCL 02-057 is a 12V, 4-pin, normally open contact high load maxi relay with resistor protection, designed as a general-purpose switching component for automotive and commercial vehicle electrical systems. Its normally open configuration means the load circuit remains open at rest and closes when the relay is energised, making it well suited to applications where a secondary circuit must be activated by a control signal.
The relay is rated for a continuous load of 70A when the contact is closed, with a peak load capacity of 140A - figures that allow it to handle high-demand circuits such as additional lighting, cooling fans, horns, and similar ancillary loads. Resistor protection is incorporated into the design, helping to suppress voltage spikes and safeguarding sensitive control electronics from back-EMF generated when inductive loads are switched.
The unit features two 6.3mm terminals, providing a secure and widely compatible blade connection suitable for standard automotive wiring connectors. The 4-pin layout follows a conventional relay footprint, keeping installation straightforward for the experienced workshop technician.
About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Voltage | 12V |
|---|---|
| Continuous Load | 70 Amps |
| Peak Load | 80 Amps |
| Operation Life | 100,000 Operations At 80A |
| Contact Material | Agsn02 |
| Output Contact | 1 (No 87) |
| Terminal Sizes | 2 X 6.3Mm & 2 X 9.5Mm |
| Ambient Temperature | -40°C To +85°C |
| Case Material | Pa66 |
| Bracket Type | None |
| Protection | Resistor |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Mini Relay - 4 Pin, Open Contact, 12V, CCL - 02-057
|
Open Now |
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
||||||||||
| Technical Specification | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | 02-001 | 02-002 | 02-003 | 02-004 | 02-007 | 02-008 | 02-009 | 02-010 | 02-011 | 02-012 |
A. The CCL 02-057 is rated for a continuous load of 70A and a peak load of 140A when the contact is closed.
A. The 02-057 uses a normally open contact configuration, meaning the load circuit is open at rest and closes when the relay coil is energised.
A. The relay is designed for 12V electrical systems.
A. Yes. Every vehicle and OE cross-reference shown for this part is checked against manufacturer data and backed by our Fit Guarantee. If it is not right, our Fit Guarantee or hassle-free returns have you covered.
