Product Number: 02-001
The CCL 02-001 is a 12V four-pin mini relay with a normally open contact configuration, designed for switching electrical circuits in automotive, commercial vehicle, and light industrial applications. Rated at 40A continuous load and 80A peak load when closed, it is suited to demanding switched circuits where a compact relay footprint is required.
The relay features four terminals each accepting a 6.3mm connector, providing a clean and secure connection without specialist tooling. The open-contact design means the circuit remains broken at rest and closes only when the relay coil is energised, making it appropriate for standard switching duties such as auxiliary lighting, horn circuits, and ancillary electrical loads.
An optional metal bracket is available for applications where the relay requires a fixed mounting point, offering flexibility in installation across a range of vehicle types and panel configurations. The 12V coil voltage makes the 02-001 directly compatible with standard 12V vehicle electrical systems.
Contents include the relay unit. No fitment-specific vehicle applications are confirmed in current source data. The CCL 02-001 is manufactured in Taiwan.
About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| TYPE | 4 Pin normally open contact Mini Relay. |
|---|---|
| VOLTAGE | 12V |
| CONTINUOUS LOAD | 40A |
| PEAK LOAD | 80A |
| BRACKET TYPE | Optional Metal |
| TERMINAL SIZES | 4 x 6.3mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £2.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
||||||||||
| Technical Specification | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | 02-002 | 02-003 | 02-004 | 02-007 | 02-008 | 02-009 | 02-010 | 02-011 | 02-012 | 02-013 |
A. The 02-001 is rated at 40A continuous load and 80A peak load when the contact is closed.
A. The relay has four terminals, each accepting a 6.3mm connector.
A. A normally open contact means the circuit is open (broken) when the relay is at rest. The circuit closes only when the relay coil is energised by the control signal.
A. Yes. Every vehicle and OE cross-reference shown for this part is checked against manufacturer data and backed by our Fit Guarantee. If it is not right, our Fit Guarantee or hassle-free returns have you covered.
