Product Number: 02-034
The CCL 02-034 is a Changeover High Load Maxi Relay With Resistor Protection, rated at 12V and designed for high-demand switching applications in automotive, commercial vehicle, and related electrical systems. Its built-in resistor protection makes it a dependable choice where coil suppression is required to safeguard connected electronics.
The relay delivers substantial current-handling capability across both switching states. In the open (normally-open) circuit, it carries a continuous load of 150A and a peak load of 200A. In the closed (normally-closed) circuit, it is rated for a continuous load of 60A and a peak load of 100A. This combination of high open-state capacity and robust closed-state rating makes the 02-034 well suited to the kind of high-load switching demands found in vehicle power distribution, starter circuits, and auxiliary load management.
The 5-pin changeover configuration provides both normally-open and normally-closed switching in a single unit, offering flexible installation options for a range of circuit designs. Connections are made via two 6.3mm terminals, a widely used standard that ensures compatibility with commonly available relay connectors and wiring accessories.
No vehicle-specific fitment data is available for this product in the current source records. Buyers should verify suitability against the circuit specifications of their application prior to installation.
About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| TYPE | 5 pin changeover High Load Maxi Relay with Resistor protection. |
|---|---|
| VOLTAGE | 12V |
| CONTINUOUS LOAD (OPEN) | 150A |
| CONTINUOUS LOAD (CLOSED/SWITCHED) | 60A |
| PEAK LOAD (OPEN) | 200A |
| PEAK LOAD (CLOSED / SWITCHED) | 100A |
| BRACKET TYPE | None |
| TERMINAL SIZES | 2 x 6.3mm, 3 x 9.5 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £2.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
||||||||||
| Technical Specification | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | 02-001 | 02-002 | 02-003 | 02-004 | 02-007 | 02-008 | 02-009 | 02-010 | 02-011 | 02-012 |
A. The 02-034 is rated at 150A continuous and 200A peak in the open (normally-open) circuit, and 60A continuous and 100A peak in the closed (normally-closed) circuit.
A. The 02-034 is a 12V relay, suitable for 12-volt DC electrical systems.
A. The built-in resistor protection suppresses voltage spikes generated when the relay coil is de-energised, helping to protect sensitive electronic components connected to the same circuit.
A. Yes. Every vehicle and OE cross-reference shown for this part is checked against manufacturer data and backed by our Fit Guarantee. If it is not right, our Fit Guarantee or hassle-free returns have you covered.
