Product Number: 02-036
The CCL 02-036 is a 12V normally open contact high load Maxi Relay with resistor protection, designed for high-current switching applications in automotive, commercial vehicle, and heavy-duty electrical systems. With a continuous load rating of 100A and a peak load capacity of 200A, this relay is built for demanding circuits where reliable, high-amperage control is essential.
The normally open contact configuration means the circuit remains open at rest and closes when the relay is energised, making it suitable for load-switching duties where power is required only on demand. Resistor protection is incorporated into the design to suppress voltage spikes and protect sensitive control electronics from back-EMF generated when inductive loads - such as motors, solenoids, and fans - are switched off.
The relay features a 4-pin terminal arrangement with two 6.3mm blade connectors, providing a secure and standardised connection within the vehicle or machine wiring loom. The Maxi Relay form factor is widely used across professional automotive and plant electrical installations, ensuring straightforward fitment into compatible relay holders and fuse boxes.
For the complete CCL relay range - including variants in different voltage ratings, contact configurations, and terminal layouts - please refer to the wider 02-series range on the PartsForMachines platform.
About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| TYPE | 4 Pin normally open contact High Load Maxi Relay with Resistor protection. |
|---|---|
| VOLTAGE | 12V |
| CONTINUOUS LOAD | 100A |
| PEAK LOAD | 200A |
| BRACKET TYPE | None |
| TERMINAL SIZES | 2 x 6.3mm, 2 x 9.5mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
||||||||||
| Technical Specification | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | 02-001 | 02-002 | 02-003 | 02-004 | 02-007 | 02-008 | 02-009 | 02-010 | 02-011 | 02-012 |
A. The CCL 02-036 is rated for a continuous load of 100A and a peak load of 200A when the contact is closed, making it suitable for high-current switching duties in 12V electrical systems.
A. A normally open contact means the relay circuit is open — and therefore no current flows through the load — when the relay is at rest. The contact closes and completes the circuit only when the relay coil is energised.
A. Resistor protection suppresses voltage spikes caused by back-EMF when inductive loads such as motors, solenoids, or fans are switched off. This helps protect sensitive control electronics and the vehicle's ECU from transient voltage damage.
