Product Number: 02-030
The CCL 02-030 is a 12-volt, 4-pin, open-contact relay with integrated resistor protection, designed as a direct-fit replacement for automotive, commercial vehicle, and plant electrical systems. Supplied under the CCL Japanese Type Relay designation, it is built to deliver reliable switching performance in demanding vehicle electrical environments.
The relay operates at 12V and is rated for a continuous load of 30A on the closed contact, with a peak load capacity of 60A - making it well suited to higher-demand switching applications such as auxiliary lighting, cooling fans, horns, and other resistive or inductive loads. The integrated resistor protection circuit suppresses voltage spikes generated when inductive loads switch off, helping to protect sensitive control modules and surrounding components from back-EMF damage.
With an open-contact configuration and a standard 4-pin layout, the 02-030 follows the widely used Japanese-type relay format, facilitating straightforward installation in existing relay sockets and wiring harnesses without modification. This makes it a practical and dependable choice for workshops carrying out routine relay replacement on a broad range of vehicles and machines.
This relay is a standalone general replacement part. No fitment data is available from source; compatibility should be confirmed against vehicle or circuit specifications prior to ordering. For the CCL relay range, please refer to the full 02-series listings on the PartsForMachines platform.
About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| TYPE | 4 Pin normally open contact Exact Fit replacement Relay with Resistor protection. |
|---|---|
| VOLTAGE | 12V |
| CONTINUOUS LOAD | 30A |
| PEAK LOAD | 60A |
| BRACKET TYPE | None |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £2.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
||||||||||
| Technical Specification | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | 02-001 | 02-002 | 02-003 | 02-004 | 02-007 | 02-008 | 02-009 | 02-010 | 02-011 | 02-012 |
A. The 02-030 operates at 12V and is rated for a continuous load of 30A and a peak load of 60A on the closed contact.
A. The integrated resistor protection suppresses voltage spikes caused by inductive loads switching off, helping to shield vehicle control modules and other electronic components from back-EMF damage.
A. The 02-030 uses a standard 4-pin, open-contact layout in the Japanese-type relay format, compatible with widely used relay sockets and wiring harnesses.
A. Yes. Every vehicle and OE cross-reference shown for this part is checked against manufacturer data and backed by our Fit Guarantee. If it is not right, our Fit Guarantee or hassle-free returns have you covered.
