Product Number: 13-001
The CCL 13-001 is a 4-pin, normally open contact micro relay rated at 12 volts, designed as a compact switching solution for automotive and vehicle electrical systems. Built for general replacement duty, it offers a reliable, space-saving alternative where a standard-footprint relay is not required.
The 13-001 operates on a normally open contact configuration, meaning the circuit remains open at rest and closes when the relay coil is energised. It is rated for a continuous load of 40A when closed and can handle a peak load of 80A, making it capable of switching high-current circuits such as auxiliary lighting, horns, pumps, and other vehicle accessories. Both terminals use a 2 x 4.8 mm connector format, which suits a wide range of standard automotive wiring harnesses and relay bases.
As a micro relay, the 13-001 occupies a smaller footprint than a standard relay whilst delivering the same core switching performance. This makes it well suited to installations where space is limited, including modern passenger cars, light commercial vehicles, and plant or agricultural machinery where compact relay housings are specified.
No variant siblings are listed at this time. For applications requiring alternative configurations, please refer to the wider CCL relay range available on the PartsForMachines platform.
The CCL 13-001 is a standalone general replacement part supplied as a single unit. Please refer to the product listing for full warranty and despatch information.
About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| TYPE | 4 Pin normally open contact Mirco Relay |
|---|---|
| VOLTAGE | 12 |
| CONTINUOUS LOAD | 40A |
| PEAK LOAD | 80A |
| BRACKET TYPE | None |
| TERMINAL SIZES | 2 x 4.8mm, 2 x 6.3mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
||||||||||
| Technical Specification | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | 02-001 | 02-002 | 02-003 | 02-004 | 02-007 | 02-008 | 02-009 | 02-010 | 02-011 | 02-012 |
A. The CCL 13-001 is rated at 12 volts DC, making it suitable for standard automotive and light commercial vehicle electrical systems.
A. The relay is rated for a continuous load of 40A when the contact is closed and a peak load of 80A, allowing it to switch high-current circuits including auxiliary lighting, horns, and pumps.
A. The 13-001 uses 2 × 4.8 mm terminals, which are compatible with a wide range of standard automotive wiring harnesses and relay bases.
A. Yes. Every vehicle and OE cross-reference shown for this part is checked against manufacturer data and backed by our Fit Guarantee. If it is not right, our Fit Guarantee or hassle-free returns have you covered.
