Product Number: 1422-060
The 1422-060 is a compression latch from the 1422 series, fitted with a 10mm male hexagon insert and finished in black powder coat. It is purpose-built for panel-mounted enclosure and cabinet applications where a secure, adjustable compression closure is required, and carries an IP65 ingress-protection rating to suit demanding workshop and industrial environments.
The latch housing and cylinder are constructed from zinc die-cast alloy with a black powder-coated finish, while the cam and shaft are mild steel with zinc plating. The 10mm male hexagon drive allows operation with standard hex keys. A cam is included with the unit.
The 1422-060 accepts a panel cutout of 19.5 x 19.5 mm and accommodates panel thicknesses from 1 mm to 16 mm. The adjustable grip range covers five selectable settings: 11.4–27.2 mm, 25.4–28.6 mm, 38.9–54.6 mm, 52.6–68.3 mm, and 66.3–76.2 mm, giving substantial flexibility across varying door and panel assemblies. A bright chrome finish variant is available for this model series; contact PartsForMachines for further information.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Cam Option | Cam included |
|---|---|
| Colour/Finish | Black Powder Coated |
| Grip Range | 11.4-27.2mm, 25.4-28.6mm, 38.9-54.6mm, 52.6-68.3mm, 66.3-76.2mm |
| IP Rating | IP65 |
| Lock Types | Male Hexagon 10mm |
| Material | Mild Steel Zinc Plated Shaft, Zinc Die, Zinc Die Body |
| Model | 1422 |
| Panel Cutout | 19.5x19.5mm |
| Panel Thickness | 1 - 16mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||||||||||||
| Technical Specification | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | 1421-05 | 1421-04 | 1421-20 | 1421-08 | 1422-013 | 1422-047 | 1422-037 | 1422-068 | 1422-048 | 1422-038 | 1422-05 | 1422-20 | 1422-07 | 1423-048-30.S01 | 1423-013-10 |
A. The 1422-060 uses a 10mm male hexagon insert, operated with a standard 10mm hex key.
A. The latch requires a 19.5 x 19.5 mm panel cutout and accommodates panel thicknesses from 1 mm to 16 mm.
A. The adjustable grip range covers five settings: 11.4–27.2 mm, 25.4–28.6 mm, 38.9–54.6 mm, 52.6–68.3 mm, and 66.3–76.2 mm.
A. The 1422-060 is rated IP65, indicating protection against dust ingress and low-pressure water jets.
A. The housing and cylinder are die-cast zinc alloy with a black powder-coated finish. The cam and shaft are mild steel with zinc plating.
A. Yes, a cam is included with the latch.
A. Yes, a bright chrome finish variant is available for the 1422 series. Contact PartsForMachines for further details.
A. Standard UK mainland delivery is 3–5 working days. Next-day delivery is available on most products and will appear as an option at checkout where eligible.
