Product Number: 1422-20
The 1422-20 is a tubular key operated compression latch finished in black powder coated die cast zinc alloy, designed for secure panel fastening across industrial enclosure and cabinet applications. The IP65-rated housing and cylinder are constructed from zinc die cast alloy, with a mild steel zinc plated cam and shaft included as standard.
The adjustable grip range is a defining characteristic of this latch, accommodating five panel thickness ranges: 11.4–27.2 mm, 25.4–28.6 mm, 38.9–54.6 mm, 52.6–68.3 mm, and 66.3–76.2 mm. This flexibility makes the 1422-20 suitable for a wide variety of enclosure wall thicknesses without requiring separate part selection for each application. The fixing aperture required is 19.5 × 19.5 mm.
The tubular key cylinder provides a higher level of security than standard quarter-turn or wing-knob alternatives, making this latch appropriate for enclosures requiring controlled access. The IP65 ingress protection rating confirms resistance to dust ingress and low-pressure water jets, supporting use in demanding workshop, outdoor, and industrial environments. A bright chrome finish variant is available; contact us for further information on that option.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Cam Option | Cam included |
|---|---|
| Colour/Finish | Black Powder Coated |
| Grip Range | 11.4-27.2mm, 25.4-28.6mm, 38.9-54.6mm, 52.6-68.3mm, 66.3-76.2mm |
| IP Rating | IP65 |
| Lock Types | Tubular (Key Operated) |
| Material | Mild Steel Zinc Plated Shaft, Zinc Die, Zinc Die Body |
| Model | 1422 |
| Panel Cutout | 19.5x19.5mm |
| Panel Thickness | 1 - 16mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1409-110-3520 | 1421-04 | 1421-05 | 1421-08 | 1421-20 |
| Type | Compression Lock | Compression Lock | Compression Lock | Compression Lock | Compression Lock |
| Grip Range | 35.3-51mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm |
| Panel Thickness | 1 - 27mm | 1 - 10mm | 1 - 10mm | 1 - 10mm | 1 - 10mm |
A. The 1422-20 uses a tubular key operated cylinder, providing controlled access security for industrial enclosures and cabinets.
A. The panel cutout required is 19.5 × 19.5 mm.
A. The 1422-20 accommodates five grip ranges: 11.4–27.2 mm, 25.4–28.6 mm, 38.9–54.6 mm, 52.6–68.3 mm, and 66.3–76.2 mm, covering a wide span of panel thicknesses.
A. The 1422-20 carries an IP65 rating, confirming protection against dust ingress and low-pressure water jets.
A. The housing and cylinder are die cast zinc alloy with a black powder coated finish. The cam and shaft are mild steel, zinc plated.
A. Yes — a cam is included as standard with the 1422-20.
A. Yes — a bright chrome finish variant is available. Contact us directly for further information on that option.
