Product Number: 1422-047
Variations
The 1422-047 is a compression latch from the 1422 series, featuring a 7mm square insert drive and a black powder coated finish. Designed for panel mounting applications, it carries IP65 ingress protection, making it suitable for enclosures and cabinets where resistance to dust and water ingress is required.
The latch housing and cylinder are constructed from zinc die cast alloy with a black powder coated finish. The cam and shaft are manufactured from mild steel with zinc plating. A cam is included as standard. A bright chrome finish variant is also available — contact PartsForMachines for details.
The 1422-047 accepts a panel cutout of 19.5 x 19.5 mm and accommodates panel thicknesses from 1 mm to 16 mm. The adjustable grip covers a wide combined range: 11.4–27.2 mm, 25.4–28.6 mm, 38.9–54.6 mm, 52.6–68.3 mm, and 66.3–76.2 mm, providing versatility across varied installation depths.
Related compression latch series available at PartsForMachines include the 1421, 1423, 1409, 1437 wing-knob, 1241 large type, and 1241 small type series, as well as the 1439 series.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Cam Option | Cam included |
|---|---|
| Colour/Finish | Black Powder Coated |
| Grip Range | 11.4-27.2mm, 25.4-28.6mm, 38.9-54.6mm, 52.6-68.3mm, 66.3-76.2mm |
| IP Rating | IP65 |
| Lock Types | Square 7mm |
| Material | Mild Steel Zinc Plated Shaft, Zinc Die, Zinc Die Body |
| Model | 1422 |
| Panel Cutout | 19.5x19.5mm |
| Panel Thickness | 1 - 16mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1409-110-3520 | 1421-04 | 1421-05 | 1421-08 | 1421-20 |
| Type | Compression Lock | Compression Lock | Compression Lock | Compression Lock | Compression Lock |
| Grip Range | 35.3-51mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm |
| Panel Thickness | 1 - 27mm | 1 - 10mm | 1 - 10mm | 1 - 10mm | 1 - 10mm |
A. The 1422-047 requires a panel cutout of 19.5 x 19.5 mm.
A. The latch accommodates panel thicknesses from 1 mm to 16 mm.
A. The adjustable grip covers the following ranges: 11.4–27.2 mm, 25.4–28.6 mm, 38.9–54.6 mm, 52.6–68.3 mm, and 66.3–76.2 mm.
A. The 1422-047 carries an IP65 ingress protection rating.
A. The housing and cylinder are die cast zinc alloy with a black powder coated finish. The cam and shaft are mild steel with zinc plating.
A. Yes, a cam is included as standard. The latch uses a 7mm square insert drive.
A. Yes, a bright chrome finish variant is available. Contact PartsForMachines for further information.
A. In-stock orders placed before 14:30 Monday to Friday are usually dispatched the same day.
