Product Number: 1421-20
The 1421-20 is a mini compression latch in the 1421 series, finished in black powder coated cast zinc body featuring a mild steel zinc plated shaft and cam. Designed for panel-mounted applications requiring a tubular key operated locking mechanism, it carries IP65-grade weather sealing and ships with the cam included.
The adjustable grip range is a defining practical feature of this latch. Eight grip ranges are available — 3.2–6.4 mm, 6.4–9.5 mm, 9.5–12.7 mm, 12.7–15.9 mm, 15.9–19 mm, 19–22.2 mm, 22.2–25.4 mm, and 25.4–28.6 mm — making it suitable for panel thicknesses from 1 mm to 10 mm. The fixing aperture required is 13.5 × 16 mm. A bright chrome finish variant is also available; contact PartsForMachines for further information.
The 1421 series is part of a broader family of compression latches. Related series available from PartsForMachines include the 1422, 1423, 1409, 1437 wing-knob, 1439, and 1241 (large and small type) compression latch ranges.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Cam Option | Cam included |
|---|---|
| Colour/Finish | Black Powder Coated |
| Grip Range | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm |
| IP Rating | IP65 |
| Lock Types | Tubular (Key Operated) |
| Material | Mild Steel Zinc Plated Shaft, Zinc Die, Zinc Die Body |
| Model | 1421 |
| Panel Cutout | 13.5x16mm |
| Panel Thickness | 1 - 10mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1409-110-3520 | 1421-04 | 1421-05 | 1421-08 | 1422-013 |
| Type | Compression Lock | Compression Lock | Compression Lock | Compression Lock | Compression Lock |
| Size | 3mm | ||||
| Grip Range | 35.3-51mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 11.4-27.2mm, 25.4-28.6mm, 38.9-54.6mm, 52.6-68.3mm, 66.3-76.2mm |
| Panel Thickness | 1 - 27mm | 1 - 10mm | 1 - 10mm | 1 - 10mm | 1 - 16mm |
| Size Range | Up to 10mm | ||||
A. The 1421-20 is tubular key operated, providing a secure locking mechanism for panel-mounted enclosures.
A. The 1421-20 carries an IP65 ingress protection rating.
A. A panel cutout of 13.5 × 16 mm is required.
A. The latch accommodates panel thicknesses from 1 mm to 10 mm across eight adjustable grip ranges: 3.2–6.4 mm, 6.4–9.5 mm, 9.5–12.7 mm, 12.7–15.9 mm, 15.9–19 mm, 19–22.2 mm, 22.2–25.4 mm, and 25.4–28.6 mm.
A. The body is die cast zinc alloy with a black powder coated finish. The shaft and cam are mild steel zinc plated.
A. Yes, a cam is included with the 1421-20.
A. Yes, a bright chrome finish variant is available. Contact PartsForMachines directly for further information.
A. In-stock orders placed before 14:30 Monday to Friday are usually dispatched the same day.
