Product Number: 1421-08
The 1421-08 is a mini compression latch with a wing knob handle and adjustable grip, finished in black powder coat over a die cast zinc alloy body with a mild steel zinc plated shaft and cam. Designed for secure panel fastening across a wide range of enclosures and equipment housings, it carries IP65 ingress protection and suits panel thicknesses from 1 mm to 10 mm.
The latch is supplied with cam included and is available in eight grip range options: 3.2–6.4 mm, 6.4–9.5 mm, 9.5–12.7 mm, 12.7–15.9 mm, 15.9–19 mm, 19–22.2 mm, 22.2–25.4 mm, and 25.4–28.6 mm, allowing precise clamping force to be matched to the application. The mounting cutout requirement is 13.5 × 16 mm. The latch operates in a non-locking configuration. A bright chrome finish variant is also available — contact us for further information.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Cam Option | Cam included |
|---|---|
| Colour/Finish | Black Powder Coated |
| Grip Range | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm |
| IP Rating | IP65 |
| Lock Types | Non Locking |
| Material | Mild Steel Zinc Plated Shaft, Zinc Die, Zinc Die Body |
| Model | 1421 |
| Panel Cutout | 13.5x16mm |
| Panel Thickness | 1 - 10mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1409-110-3520 | 1421-04 | 1421-05 | 1421-20 | 1422-013 |
| Type | Compression Lock | Compression Lock | Compression Lock | Compression Lock | Compression Lock |
| Size | 3mm | ||||
| Grip Range | 35.3-51mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 11.4-27.2mm, 25.4-28.6mm, 38.9-54.6mm, 52.6-68.3mm, 66.3-76.2mm |
| Panel Thickness | 1 - 27mm | 1 - 10mm | 1 - 10mm | 1 - 10mm | 1 - 16mm |
| Size Range | Up to 10mm | ||||
A. The 1421-08 is designed for panel thicknesses between 1 mm and 10 mm, with a panel cutout requirement of 13.5 × 16 mm.
A. The latch is available in eight grip range options: 3.2–6.4 mm, 6.4–9.5 mm, 9.5–12.7 mm, 12.7–15.9 mm, 15.9–19 mm, 19–22.2 mm, 22.2–25.4 mm, and 25.4–28.6 mm.
A. The 1421-08 carries an IP65 ingress protection rating.
A. The body is die cast zinc alloy with a black powder coat finish. The shaft and cam are mild steel zinc plated.
A. The cam is included with the 1421-08.
A. The 1421-08 operates in a non-locking configuration.
A. Yes — a bright chrome finish variant is available. Contact us directly for further information.
A. Yes — WhatsApp us on 07754 288583 with any questions about specifications, suitability, or compatibility.
A. WhatsApp us on 07754 288583 with photos of the item and packaging, and we will resolve the issue in line with our returns policy.
