Product Number: 1422-038
The 1422-038 is an 8mm triangle insert compression latch finished in black powder coat, designed for secure panel fastening across a wide range of enclosure and cabinet applications. The housing and cylinder are constructed from zinc die-cast alloy, with a mild steel zinc-plated cam and shaft, delivering a robust and corrosion-resistant assembly suitable for demanding industrial environments.
The latch achieves a sealed IP65 rating, making it appropriate for installations where dust exclusion and water jet resistance are required. It accepts a panel cutout of 19.5 x 19.5 mm and accommodates panel thicknesses from 1 mm to 16 mm. The adjustable grip range covers five increments: 11.4–27.2 mm, 25.4–28.6 mm, 38.9–54.6 mm, 52.6–68.3 mm, and 66.3–76.2 mm, providing flexibility across varied panel build-ups. A cam is included as standard.
A bright chrome finish variant is available within the 1422 series for applications where aesthetics or additional surface protection are a priority. For further information on the chrome-finish option, please contact the sales team directly.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Cam Option | Cam included |
|---|---|
| Colour/Finish | Black Powder Coated |
| Grip Range | 11.4-27.2mm, 25.4-28.6mm, 38.9-54.6mm, 52.6-68.3mm, 66.3-76.2mm |
| IP Rating | IP65 |
| Lock Types | Triangle 8mm |
| Material | Mild Steel Zinc Plated Shaft, Zinc Die, Zinc Die Body |
| Model | 1422 |
| Panel Cutout | 19.5x19.5mm |
| Panel Thickness | 1 - 16mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1409-110-3520 | 1421-04 | 1421-05 | 1421-08 | 1421-20 |
| Type | Compression Lock | Compression Lock | Compression Lock | Compression Lock | Compression Lock |
| Grip Range | 35.3-51mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm |
| Panel Thickness | 1 - 27mm | 1 - 10mm | 1 - 10mm | 1 - 10mm | 1 - 10mm |
A. The 1422-038 uses an 8mm triangle insert lock and is supplied in a black powder-coated finish. The housing and cylinder are zinc die-cast alloy; the cam and shaft are mild steel zinc plated.
A. The 1422-038 requires a panel cutout of 19.5 x 19.5 mm and accommodates panel thicknesses from 1 mm to 16 mm.
A. The adjustable grip covers five ranges: 11.4–27.2 mm, 25.4–28.6 mm, 38.9–54.6 mm, 52.6–68.3 mm, and 66.3–76.2 mm, allowing fitment across varied panel build-ups.
A. The 1422-038 is rated IP65, providing protection against dust ingress and water jets — suitable for industrial enclosure and cabinet installations.
A. Yes, a cam is included as standard with the 1422-038.
A. Yes, a bright chrome finish is available within the 1422 series. Please contact the sales team directly for further information on this option.
A. Yes — WhatsApp us on 07754 288583 with any questions about specifications, suitability, or compatibility.
A. WhatsApp us on 07754 288583 with photos of the item and packaging, and we will resolve the issue in line with our returns policy.
