Product Number: 1422-048
The 1422-048 is an 8mm square insert compression latch finished in black powder coat, designed for secure panel fastening across a wide range of enclosure and cabinet applications. The housing and cylinder are constructed from zinc die-cast alloy with a black powder-coated finish, while the cam and shaft are manufactured from mild steel with zinc plating for corrosion resistance.
The latch accepts a 19.5 x 19.5 mm panel cutout and accommodates panel thickness from 1 mm to 16 mm. Five grip range options are available — 11.4–27.2 mm, 25.4–28.6 mm, 38.9–54.6 mm, 52.6–68.3 mm, and 66.3–76.2 mm — providing considerable flexibility across varied enclosure depths. The hinge carries IP65 ingress protection, confirming suitability for dusty or wet environments. A cam is included as standard.
A bright chrome finish variant is also available within the 1422 series; contact PartsForMachines for further information on alternative finishes.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Cam Option | Cam included |
|---|---|
| Colour/Finish | Black Powder Coated |
| Grip Range | 11.4-27.2mm, 25.4-28.6mm, 38.9-54.6mm, 52.6-68.3mm, 66.3-76.2mm |
| IP Rating | IP65 |
| Lock Types | Square 8mm |
| Material | Mild Steel Zinc Plated Shaft, Zinc Die, Zinc Die Body |
| Model | 1422 |
| Panel Cutout | 19.5x19.5mm |
| Panel Thickness | 1 - 16mm |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1409-110-3520 | 1421-04 | 1421-05 | 1421-08 | 1421-20 |
| Type | Compression Lock | Compression Lock | Compression Lock | Compression Lock | Compression Lock |
| Grip Range | 35.3-51mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm | 3.2-6.4mm, 6.4-9.5mm, 9.5-12.7mm, 12.7-15.9mm, 15.9-19mm, 19-22.2mm, 22.2-25.4mm, 25.4-28.6mm |
| Panel Thickness | 1 - 27mm | 1 - 10mm | 1 - 10mm | 1 - 10mm | 1 - 10mm |
A. The 1422-048 uses an 8mm square insert lock type.
A. The latch requires a 19.5 x 19.5 mm panel cutout.
A. The latch accommodates panel thicknesses from 1 mm to 16 mm.
A. Five grip ranges are available: 11.4–27.2 mm, 25.4–28.6 mm, 38.9–54.6 mm, 52.6–68.3 mm, and 66.3–76.2 mm.
A. The 1422-048 carries an IP65 ingress protection rating, making it suitable for environments where dust and water ingress must be prevented.
A. The housing and cylinder are die-cast zinc alloy with a black powder-coated finish. The cam and shaft are mild steel with zinc plating.
A. Yes, a cam is included as standard with the 1422-048 compression latch.
A. Yes, a bright chrome finish is available within the 1422 series. Contact PartsForMachines for further details.
