The SL60 is an 80mm diameter SL-series anti-vibration mount fitted with an M12 thread, engineered for vibration isolation across instrument, general, and light-equipment applications where rubber-to-metal bonded construction is required. With an overall diameter (D) of 80mm, base width (B) of 70mm, height (H) of 55mm, flange dimension (F) of 105mm, lower stud length (l) of 35mm, and a spacing dimension (S) of 130mm, the SL60 occupies the larger end of its class, making it well suited to applications where its specific load envelope and deflection characteristics are matched to the installation. Constructed using rubber-to-metal bonded technology, the mount may be loaded in shear, compression, or a combination of both, giving engineers flexibility in how it is deployed within a given assembly. This bonded construction resists the forces encountered in continuous service whilst maintaining the isolation properties that protect sensitive downstream equipment and surrounding structures. The SL60 serves industries including construction and off-highway, agriculture, power generation, marine, railway and mass transit, automotive, and military and defence applications. Within these sectors it is particularly suited to protecting instruments, electronics, and light equipment from vibration-induced fatigue and damage, whilst also improving operator comfort and extending overall machinery service life. Custom options, including stainless steel metalwork and oil-resistant or high-temperature rubber compounds. Are available on request for specialist installations. This listing covers a single mount in the M12 thread and 80mm diameter configuration. For stainless steel variants or non-standard sizes, please enquire directly.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Fixing hole / dimension F (mm) | 105 |
|---|---|
| Outer diameter D (mm) | 80 |
| Width / dimension B (mm) | 70 |
| Overall height H (mm) | 55 |
| Thread / stud size M | M12 |
| Length L (mm) | 35 |
| Plate / metal thickness S (mm) | 130 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 8020PRB13 | FCM3 | FCM3I | 8240TRB25 | FCM2 |
| Type | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount |
| Size | 80mm | 81mm | 81mm | 82mm | 76mm |
| Deflection | 5 | 5 | 5 | ||
| Size Range | 51-100mm | 51-100mm | 51-100mm | 51-100mm | 51-100mm |
| Thread | M12 | M12 | M12 | ||
A. The SL60 has an outer diameter (D) of 80mm, a base width (B) of 70mm, a height (H) of 55mm, a flange dimension (F) of 105mm, a stud length (l) of 35mm, and a spacing dimension (S) of 130mm. The thread size is M12.
A. The SL60 may be loaded in shear, compression, or a combination of both, providing installation flexibility to suit different mounting configurations and equipment orientations.
A. The SL60 uses rubber-to-metal bonded construction, which integrates the rubber element with the metal hardware to resist continuous service forces whilst maintaining vibration isolation performance.
A. The SL60 is suited to construction and off-highway, agriculture, power generation, marine, railway and mass transit, automotive, and military and defence applications. It is particularly intended for isolating instruments, electronics, and light equipment from vibration.
A. Installing the SL60 helps to improve machinery lifespan, protect surrounding structures from vibration-induced damage, and improve operator comfort by absorbing and isolating vibration at source.
A. Yes — stainless steel metalwork and oil-resistant or high-temperature rubber compounds are available on request, as are additional and non-standard sizes.
A. WhatsApp us on 07754 288583 with photos of the item and packaging, and we will resolve the issue in line with our returns policy.
A. Yes — WhatsApp us on 07754 288583 with any questions about specifications, suitability, or compatibility.
