Product Number: FCM2I-60
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Top Outer Dimension (A) | 75mm |
|---|---|
| Overall Heigt (B) | 50mm |
| Thread Size (C) | M12 |
| Base Dimension (E) | 100mm |
| Flange Thickness (G) | 12.5mm |
| Overall Length (H) | 127mm |
| Max Load (kg) | 500 |
| Deflection (mm) | 5 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 10025PRB13 | 10030PRB33 | 10254TRB32 | 12246TRB38 | 12525PRB17 |
| Type | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount |
| Size | 100mm | 100mm | 102mm | 122mm | 125mm |
| Size Range | 51-100mm | 51-100mm | 101-200mm | 101-200mm | 101-200mm |
A. The FCM2I is rated to a 60° load of 500 kg, with a shore deflection of 5 mm under that load condition.
A. Dimension A (diameter) is 76 mm, B (body height) is 50 mm, thread C is M12, flange diameter E is 100 mm, flange thickness G is 12.5 mm, overall height H is 127 mm, and S (number of fixing holes) is 3.
A. The rubber-to-metal bonded construction of the FCM2I allows loading in shear, compression, or a combination of both, providing installation flexibility depending on the application.
A. This mount is designed for instruments, electronics and light equipment requiring vibration isolation. Industries served include construction and off-highway machinery, agriculture, power generation, marine, railway and mass transit, automotive, and military and defence.
A. Yes. Stainless steel metalwork and oil-resistant or high-temperature rubbers, as well as additional and custom sizes, are available on request.
A. Related mounts in this family include FCM2, FCM3, FCM3I, FCM5, FCM5I, and FCM763812. Each offers a different load capacity or dimensional configuration — refer to those listings for full specification details.
