Product Number: FCM2-60
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Top Outer Dimension (A) | 75mm |
|---|---|
| Overall Heigt (B) | 50mm |
| Thread Size (C) | M12 |
| Base Dimension (E) | 100mm |
| Flange Thickness (G) | 12.5mm |
| Overall Length (H) | 127mm |
| Max Load (kg) | 250 |
| Deflection (mm) | 5 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 10025PRB13 | 10030PRB33 | 10254TRB32 | 12246TRB38 | 12525PRB17 |
| Type | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount |
| Size | 100mm | 100mm | 102mm | 122mm | 125mm |
| Size Range | 51-100mm | 51-100mm | 101-200mm | 101-200mm | 101-200mm |
A. The FCM2 has a 60° load rating of 250 kg with a shore deflection of 5 mm.
A. The FCM2 has a diameter (A) of 76 mm, base (B) of 50 mm, M12 thread (C), flange diameter (E) of 100 mm, bolt hole (G) of 12.5 mm, overall height (H) of 127 mm, and 3 studs (S).
A. The FCM2 may be loaded in shear, compression, or a combination of both, making it adaptable to vibration inputs from more than one axis.
A. The FCM2 is designed for lightweight low-load applications — instruments, electronics, and light equipment — and is used across agriculture, marine, power generation, construction and off-highway, railway and mass transit, and automotive sectors.
A. The rubber element is bonded directly to the metal components during manufacture, creating a single integrated unit that resists separation under load and provides consistent vibration isolation performance.
A. Yes — stainless steel metalwork and oil-resistant or high-temperature rubber compounds, as well as additional and custom sizes, are available on request.
A. The range includes FCM2I (imperial-thread equivalent), FCM3, FCM3I, FCM5, FCM5I, and FCM763812, progressing through larger capacities. The FCM2 is the smallest in the range.
A. WhatsApp us on 07754 288583 with photos of the item and packaging, and we will resolve the issue in line with our returns policy.
A. In-stock orders placed before 14:30 Monday to Friday are usually dispatched the same day.
