Product Number: 5016PRB11
Compact at 50 mm outer diameter and just 16 mm in height, the 5016PRB11 ring element is engineered for lighter, sensitivity-driven installations where vibration isolation takes priority over high load capacity. Its rubber-to-metal bonded construction delivers reliable performance in applications such as instrument mounting, electronics, and light equipment protection across industries including agriculture, marine, power generation, and automotive. The ring element format allows loading in shear, compression, or a combination of both, giving installation engineers flexibility when addressing vibration paths in confined or weight-critical assemblies. Softer rubber hardness grades within this family deliver greater deflection and superior isolation at lower operating loads, which makes this geometry well suited to sensitive equipment where minimising transmitted vibration is the principal design objective. By absorbing vibratory energy, the mount helps extend machinery service life, protects adjacent structures, and contributes to improved operator comfort. Key dimensions for the 5016PRB11 are: outer diameter (D) 50 mm, height (H) 16 mm, inner bore d1 20 mm, inner bore d2 11 mm, and stiffness factor S 3. These figures define the mount's load-deflection behaviour and must be matched to the installation envelope and load requirements. Custom configurations, including stainless steel metalwork and oil-resistant or high-temperature rubber compounds, are available on request. Additional ring element variants in the range include 10254TRB32, 12246TRB38, 4223TRB18, 6233TRB21, 7233TRB21, 8240TRB25, RE10027, and RE11015, covering a wider spread of sizes and load capacities for different installation demands. Manufactured to rubber-to-metal bonded construction standards, the 5016PRB11 is supplied as a standalone mount.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Outer diameter D (mm) | 50 |
|---|---|
| Overall height H (mm) | 16 |
| Diameter / thread d1 (mm) | 20 |
| Diameter / thread d2 (mm) | 11 |
| Plate / metal thickness S (mm) | 3 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | CM507 | CM508 | RE1/53/32.5 | 4223TRB18 | 4016PRB09 |
| Type | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount |
| Size | 50.8mm | 50.8mm | 53mm | 42mm | 40mm |
| Size Range | 51-100mm | 51-100mm | 51-100mm | 26-50mm | 26-50mm |
A. The 5016PRB11 has an outer diameter (D) of 50 mm, a height (H) of 16 mm, an inner bore d1 of 20 mm, an inner bore d2 of 11 mm, and a stiffness factor (S) of 3.
A. The ring element can be loaded in shear, compression, or a combination of both, providing installation flexibility to suit a range of vibration isolation requirements.
A. It is designed for instrument and general mountings, particularly where lighter loads and vibration sensitivity are the primary concerns. Typical industries include agriculture, marine, power generation, automotive, construction and off-highway, railway and mass transit, and military and defence.
A. Softer rubber grades provide greater deflection and better vibration isolation at lower loads. Harder grades carry higher loads with less movement. Hardness selection should be matched to the operating load and isolation requirements of the installation.
A. Yes. Stainless steel metalwork and oil-resistant or high-temperature rubber compounds are available on request, along with additional and custom sizes.
A. Related variants include 10254TRB32, 12246TRB38, 4223TRB18, 6233TRB21, 7233TRB21, 8240TRB25, RE10027, and RE11015, offering different sizes and load capacities to suit a wider range of installations.
