At 48mm diameter, the CTM4823 is the entry point of the Captive Transit Mount range, engineered for lighter-duty mobile and static applications where controlled movement and reliable vibration attenuation are essential within a compact envelope. Its load capacity and deflection characteristics are matched to the lower end of the family's 20 kg–5,000 kg span, making it well suited to smaller generating sets, light pumps and compressors, and auxiliary power units in commercial vehicles. The mount's design centres on rubber-to-metal bonded construction in which the elastomer operates in shear-compression for optimum performance and vibration reduction of up to 95% across all axes. An integral overload stop limits equipment movement during transit, while a failsafe arrangement governs shock loads to prevent catastrophic failure. The metal top cap shields the rubber element from oil, fuel and general contamination, and protective plating guards the metal components against corrosion. Specification data for the CTM4823 is as follows: external diameter (A) 48 mm, body height (B) 23 mm, port thread (P) M6/M8, fixing pin diameter (F×M) 6.1 mm, centring flange (CF) 68 mm, groove dimension (G) 34 mm, overall length (L) 84 mm, and deflection static (S) 2.0 mm. Mounts may be loaded in shear, compression, or a combination of both. Custom configurations including stainless steel metalwork and oil-resistant or high-temperature rubber compounds are available on request. This mount is a single-diameter variant.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Overall length / diameter A (mm) | 48 |
|---|---|
| Width / dimension B (mm) | 23 |
| Pitch / dimension P (mm) | M6/M8 |
| Fixing hole F (mm) / Thread / stud size M | 6.1ø |
| Across flats / clearance CF (mm) | 68 |
| Fixing hole spacing G (mm) | 34 |
| Length L (mm) | 84 |
| Plate / metal thickness S (mm) | 2 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | CTM-R | CTM-R2 | CTM-R3 | CTM10638 | CTM1063812-45 |
| Type | Captive Mount | Captive Mount | Captive Mount | Captive Mount | Captive Mount |
| Size | 64mm | 106mm | |||
| Deflection | 3.5mm | 3.5mm | 4mm | ||
| Size Range | 51-100mm | 101-200mm | |||
| Thread | M12 | M12 | M12 | M12 | M12 |
A. The CTM4823 uses rubber-to-metal bonded construction with the elastomer operating in shear-compression, achieving vibration reduction of up to 95% across all axes.
A. The integral overload stop controls the movement of mounted equipment during transit. The failsafe arrangement governs shock loads and prevents catastrophic failure should the primary isolation element be overloaded.
A. External diameter (A) 48 mm, body height (B) 23 mm, thread (P) M6/M8, fixing pin diameter (F×M) 6.1 mm, centring flange (CF) 68 mm, groove dimension (G) 34 mm, overall length (L) 84 mm, and static deflection (S) 2.0 mm.
A. The CTM4823 suits smaller generating sets, light pumps and compressors, diesel and marine engines, and auxiliary systems in commercial and industrial vehicles — both mobile and static installations.
A. The metal top cap shields the rubber element against oil, fuel and general contamination. Protective plating on the metalwork additionally resists corrosion in demanding operating environments.
A. Yes. The mount may be loaded in shear, compression, or a combination of both, giving installation flexibility across different machinery configurations.
A. Yes. Stainless steel metalwork and oil-resistant or high-temperature rubber compounds are available on request, as are additional and custom sizes within the Captive Transit Mount family.
A. The range includes CTM-R, CTM10638, CTM10642, CTM10850, CTM11548, CTM12142, CTM12548, and CTM14448, covering a wide spread of diameters and load ratings up to 5,000 kg.
