Product Number: ATP50241212-70
Variations
When the load is high and the M12-fixed unit must not shift, the firmest rubber is specified. On a Ø50 mm armoured plate with an M12 stud and 22 mm bore, this two-piece mount is rated in 70 Shore A to 377 kg per mounting, the top figure for this plate. The hard compound resists deflection, holding heavy compressors and engines firmly while the bonded rubber still breaks the shock and vibration path. Its captive construction resists pull-off under impact and reversing duty on mobile equipment. Where more isolation and a lower working load are wanted from the same plate, the softer [ATP50241212-45] and [ATP50241212-60] are the alternatives. The combination of a strong M12 fixing and a stiff element makes it the pick where a compact mount must not creep under a sustained heavy load. Standard and bespoke variants are produced to order. Even under a continuous heavy duty the bonded element holds its shape, so the mounted height stays stable over time. Stainless steel metalwork and oil-resistant or high-temperature rubbers are available on request.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | ATP3615106-45 | ATP3615106-60 | ATP3615106-70 | ATP3615166-45 | ATP3615166-60 |
| Type | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount |
| Size | 6.2mm | 6.2mm | 6.2mm | 6mm | 6mm |
| Size Range | Up to 10mm | Up to 10mm | Up to 10mm | Up to 10mm | Up to 10mm |
A. In 70 Shore A this Armoured Plate mount supports up to 377 kg per mounting.
A. Rubber is bonded between a base plate and a top fixing, giving a captive two-piece mount that isolates vibration and locates the equipment.
A. Yes — it works in compression, shear, or a combination of the two.
A. Softer grades give more isolation at lower load; firmer grades carry more load with less movement. Match the grade to your load.
A. Standard UK mainland delivery is 3–5 working days.
