Product Number: ATP3615106-45
Variations
Rated to a maximum load of 97 kg and measuring 36 mm in diameter with an A/B dimension of 6.2 mm, this two-piece armoured plate mount in 45 Shore A rubber is selected where maximum vibration isolation and generous deflection under load take priority over restraint. The softer rubber compound yields freely under lighter dynamic forces, absorbing and dissipating energy at lower frequencies where isolation performance matters most, making it well suited to sensitive instrumentation, compact electrical enclosures, and lighter fabricated assemblies that require protection from recurring vibration rather than heavy shock containment. Rubber-to-metal bonded construction bonds the elastomer directly to the armoured plate hardware, ensuring reliable load transfer and consistent deflection characteristics across the mount's service life. The geometry, 36 mm diameter, C dimension 15 mm, E dimension 10 mm, F dimension 6 mm, S dimension 1. Provides a defined contact envelope suited to installations where space is constrained. At 45 Shore A, the rubber grades softer within this family, delivering greater movement under equivalent load than the 60 Shore A or 70 Shore A variants; that characteristic is the defining reason to specify this grade for lower-load isolation duties. Typical application sectors for rubber bump stops and buffers of this type include industrial machinery, agricultural equipment, construction equipment, commercial vehicles, and elevators. The mount may be loaded in compression, shear, or a combination of both, and its energy-absorbing action helps protect surrounding structures, extend machinery service life, and reduce vibration transmitted to operators.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | ATP361883-45 | ATP361883-60 | ATP361883-70 | ATP362083-45 | ATP362083-60 |
| Type | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount |
| Size | 16.6mm | 16.6mm | 16.6mm | 16.6mm | 16.6mm |
| Size Range | 11-25mm | 11-25mm | 11-25mm | 11-25mm | 11-25mm |
A. The ATP3615106-45 armoured plate mount is rated to a maximum load of 97 kg.
A. The mount has a diameter (D) of 36 mm, A and B dimensions of 6.2 mm each, C dimension of 15 mm, E dimension of 10 mm, F dimension of 6 mm, and an S value of 1. All dimensions are in millimetres.
A. At 45 Shore A, this is the softer grade within the armoured plate mount range. Softer rubber gives greater deflection under load and better vibration isolation at lower frequencies, making it the appropriate choice for lighter or sensitive equipment where isolation performance is the priority rather than high-load restraint.
A. Rubber bump stops and buffers of this type are used across industrial machinery, agricultural equipment, construction equipment, commercial vehicles, and elevators. The mount absorbs and dissipates energy to protect surrounding structures, extend machinery service life, and reduce vibration transmitted to operators.
A. The mount may be loaded in compression, shear, or a combination of both, depending on the requirements of the installation.
A. Yes — stainless steel hardware and oil-resistant or high-temperature rubber compounds are available on request, along with additional and custom sizes.
A. The same 36 mm diameter, 6.2 mm A/B profile is available in 60 Shore A (ATP3615106-60) and 70 Shore A (ATP3615106-70). Further geometry variants include ATP3615166, ATP3618104, ATP361883, ATP362083, ATP50241210, and ATP50241212.
