Product Number: PB12075-STEEL
At 150mm across its seating diameter (A), the PB12075-STEEL is the smallest steel-bodied tipper body pad in the range, and its compact load band makes it the natural starting point when specifying hollow rubber spring buffers for lightly loaded tipper body contact points. Designed as a hollow rubber spring, it functions as a buffer and bump-stop shock absorber, with progressive stiffness built in to manage impact energy smoothly rather than transferring it as a sharp spike to the body structure or chassis. Constructed with rubber-to-metal bonded technology, the pad combines a steel body with a rubber working element to deliver maintenance-free service and high fatigue life across repeated deflection cycles. Progressive stiffness means resistance increases progressively under load, giving controlled energy absorption that protects both the tipper body and surrounding structures. The design is inherently maintenance free, with no lubrication points or wear surfaces requiring periodic attention. Key dimensional references for fitment planning: seating diameter A 150mm, overall height H 14mm, outer diameter D1 180mm, inner diameter D2 120mm, bearing diameter D3 75mm, bore diameter d 6.8mm, and section S 3mm. These figures govern correct selection against body rail geometry and fastener sizing. The pad is suited to vehicle suspension contact applications, commercial and off-road vehicle bodywork, trailer body buffers, construction equipment body restraints, and agricultural equipment impact points where a compact, low-profile bump-stop is required. This 150mm pad sits at the entry point of the steel tipper body pad range.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Overall length / diameter A (mm) | 150 |
|---|---|
| Overall height H (mm) | 14 |
| Diameter / thread d1 (mm) | 180 |
| Diameter / thread d2 (mm) | 120 |
| Diameter / thread d3 (mm) | 75 |
| Fixing thread / bolt size d | 6.8 |
| Plate / metal thickness S (mm) | 3 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | PB1137434 | PB1167550 | 1514MRF13 | 2024MFR18 | 2519MRF18 |
| Type | Pad | Pad | Pad | Pad | Pad |
| Size | 151mm | 151mm | 15mm | 20mm | 25mm |
| Size Range | 101-200mm | 101-200mm | 11-25mm | 11-25mm | 11-25mm |
| Thread | M4 | M6 | M6 | ||
A. The PB12075-STEEL has a seating diameter (A) of 150mm, overall height (H) of 14mm, outer diameter (D1) of 180mm, inner diameter (D2) of 120mm, bearing diameter (D3) of 75mm, bore diameter (d) of 6.8mm, and section (S) of 3mm.
A. The pad functions as a hollow rubber spring with progressive stiffness, absorbing impact energy as the tipper body contacts the chassis or body rail. Resistance increases progressively under load, managing shock smoothly rather than transmitting it as a sharp force spike to the surrounding structure.
A. The PB12075-STEEL is suited to commercial and off-road vehicles, trailers, construction equipment, and agricultural equipment — anywhere a compact low-profile bump-stop or buffer is required at a tipper body contact point.
A. No. The rubber-to-metal bonded construction is maintenance free, with no lubrication points or wear surfaces requiring periodic attention, contributing to a high fatigue life across repeated deflection cycles.
A. At 150mm seating diameter, this is the smallest steel-bodied pad in the range. Larger steel variants are available as PB1137434 and PB28675-STEEL. Aluminium-bodied options are listed as PB1167550 and PB30075-ALU.
A. Yes. Stainless steel metalwork and oil-resistant or high-temperature rubber compounds are available on request, as are additional and custom sizes.
A. We accept returns within 30 days of purchase for items that are unused, undamaged, and in their original packaging. Returns are available only for UK-delivered orders and must include proof of purchase. Before returning an item, please contact us at [email protected] to obtain a Return Merchandise Number (RMN).
A. In-stock orders placed before 14:30 Monday to Friday are usually dispatched the same day.
