Product Number: SW300-40
Engineered for maximum vibration isolation in demanding installations, the SW Mount SW300-40 is the largest SW-series mounting in the 40 Shore A soft grade, carrying a maximum load of 15,000 kg across its 270 mm diameter footprint (A: 270 mm, K: 310 mm, H: 120 mm, d: 22 mm, t: 10 mm). Where equipment is sensitive to transmitted vibration or where lower-frequency isolation is the primary objective, the soft rubber compound delivers the greatest deflection under load of any hardness grade in this geometry, making isolation efficiency the defining characteristic of this specification. The rubber-to-metal bonded construction allows the mount to be loaded in shear, compression, or a combination of both, adapting to the particular force vectors present in a given installation. The softer 40 Shore A compound maximises movement under load compared with medium or firm grades of the same size, which translates directly into superior attenuation of vibration energy before it reaches surrounding structures or operators. This is the preferred grade where machinery lifespan, protection of adjacent structures, and operator comfort take priority over maximum stiffness or positional restraint. The SW300-40 is well suited to applications in power generation, marine, railway and mass transit, agriculture, construction and off-highway, automotive, and military and defence environments. Within the SW family, this mount occupies the largest size position, making it the appropriate choice when a high total load must be managed with the compliance and isolation performance that only a soft compound can provide.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | SW300-60 | JC220.105 | JC220.524 | JC220.103 | RE1/100/21 |
| Type | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount |
| Size | 270mm | 263mm | 232mm | 202mm | 200mm |
| Size Range | Over 200mm | Over 200mm | Over 200mm | Over 200mm | 101-200mm |
A. The SW300-40 has a maximum load rating of 15,000 kg. Its dimensions are: A 270 mm, K 310 mm, H 120 mm, d 22 mm, t 10 mm.
A. A softer Shore A grade delivers greater deflection under load and better vibration isolation, particularly at lower frequencies. The 40 Shore A compound used in the SW300-40 provides the greatest movement and isolation efficiency of any hardness grade available in this geometry, making it the preferred choice where protecting sensitive equipment or surrounding structures from transmitted vibration is the primary requirement.
A. The rubber-to-metal bonded construction of this mount allows it to be loaded in shear, compression, or a combination of both, accommodating the specific force vectors of a given installation.
A. The SW300-40 is suited to power generation, marine, railway and mass transit, agriculture, construction and off-highway, automotive, and military and defence applications. It is particularly appropriate where a large, soft-grade mount is needed to isolate lighter or more vibration-sensitive equipment at high total load values.
A. Both share the same 270 mm diameter geometry (A: 270 mm, K: 310 mm, H: 120 mm, d: 22 mm, t: 10 mm) and 15,000 kg maximum load rating. The SW300-40 uses a 40 Shore A soft compound, giving greater deflection and superior vibration isolation. The SW300-60 uses a 60 Shore A firm compound, providing greater stiffness and less movement, which suits higher shock or restraint requirements. Select the grade that matches your isolation versus restraint priority.
A. Yes. Stainless steel metalwork, oil-resistant rubbers, and high-temperature rubbers are available on request, as are additional and custom sizes beyond those listed in the standard range.
A. WhatsApp us on 07754 288583 with photos of the item and packaging, and we will resolve the issue in line with our returns policy.
A. In-stock orders placed before 14:30 Monday to Friday are usually dispatched the same day.
