Product Number: CDM130-55-55
The CDM130-55-55 is a 128mm cone (cab) mount rated to a maximum load of 500 kg, specified with M30 fixings and bonded at 55 Shore A, the medium hardness grade that delivers a balanced combination of vibration isolation and structural support across a broad range of general machinery applications. At this upper-range body diameter, the mount is suited to moderate-to-substantial load demands where neither maximum deflection nor maximum rigidity is required, but a reliable middle-ground performance is essential. Constructed with rubber-to-metal bonded technology, the CDM130-55-55 exhibits high horizontal stiffness relative to its vertical stiffness, a characteristic of cone mount geometry that controls lateral movement of engines, cabs, and mounted equipment. The 55 Shore A rubber compound at this mass provides the deflection behaviour appropriate for mainstream general-machinery mounting: sufficient compliance to attenuate vibration and protect surrounding structures, yet firm enough to limit movement under moderate operational loads. Maximum bolt torque is rated at 750 N·m to M30 fixing. Key dimensions are: outer diameter (D) 128 mm, inner boss diameter (d) 30.2 mm, secondary diameter (D1) 69.2 mm, overall height (H) 58.5 mm, upper height (H1) 43 mm, clamp length (C) 70.75–71.25 mm, and dimension E 40 mm. The mount may be loaded in shear, compression, or a combination of both, making it applicable across construction and earth-moving machinery, agricultural equipment, operator cabs, and off-highway vehicles. Industries served include power generation, marine, railway and mass transit, automotive, and military and defence.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | CDM130-45-45 | CDM130-65-65 | CB1814-45 | CDM110-45-45 | CDM110-55-55 |
| Type | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount | Anti-Vibration Mount |
| Size | 128mm | 128mm | 120mm | 110mm | 110mm |
| Size Range | 101-200mm | 101-200mm | 101-200mm | 101-200mm | 101-200mm |
| Thread | M30 | M30 | M20 | M20 | |
A. The mount uses an M30 bolt fixing with a maximum bolt torque of 750 N·m.
A. Outer diameter (D) 128 mm, inner boss diameter (d) 30.2 mm, secondary diameter (D1) 69.2 mm, overall height (H) 58.5 mm, upper height (H1) 43 mm, clamp length (C) 70.75–71.25 mm, and dimension E 40 mm.
A. The 55 Shore A medium-hardness grade is suited to mainstream general-machinery mounting where a balance of vibration isolation and load support is required — typical applications include construction and earth-moving equipment, agricultural machinery, operator cabs, and off-highway vehicles.
A. Within the CDM range, softer grades (45 Shore A) give greater deflection and better isolation at lower loads, while harder grades (65 Shore A) carry higher loads with less movement. The 55 Shore A grade occupies the middle ground, offering adequate compliance for vibration attenuation alongside sufficient stiffness for moderate-to-substantial operational loads.
A. The CDM130-55-55 may be loaded in shear, compression, or a combination of both.
A. Yes — stainless steel metal components, oil-resistant rubbers, and high-temperature rubber compounds are available on request, along with additional and custom sizes.
A. The range includes 66 mm body variants (CDM66-45, CDM66-55, CDM66-65), 110 mm body variants (CDM110-45, CDM110-55, CDM110-65), and the 130 mm body in 45 Shore (CDM130-45) and 65 Shore (CDM130-65), alongside this 55 Shore 130 mm mount.
A. In-stock orders placed before 14:30 Monday to Friday are usually dispatched the same day.
A. In-stock orders placed before 14:30 Monday to Friday are usually dispatched the same day.
