Product Number: 41822
Diagnosing electrical faults on modern vehicles demands accurate, multi-function test equipment. The Draper 41822 Automotive Digital Multimeter delivers both auto and manual ranging across a comprehensive set of measurement functions — including AC and DC voltage, AC and DC current, resistance, capacitance, frequency, diode test, continuity, temperature, DWELL angle and tachometer — making it a capable single-instrument solution for automotive workshop diagnostics. The meter features a backlit LCD screen for clear readings in low-light conditions, along with MAX capture, symbol unit data hold, and an automatic power-off function to preserve battery life. An audible continuity buzzer provides instant feedback without requiring the technician to look away from the circuit under test. DWELL measurement supports 4-, 6- and 8-cylinder engines, while the tachometer covers RPM4 from 120 to 20,000 RPM and RPM2 from 60 to 20,000 RPM. Key measurement ranges include AC and DC voltage to 600 V, AC and DC current to 10 A, resistance from 600 Ω to 60 MΩ, capacitance from 40 nF to 4000 µF, frequency up to 9.999 MHz, and a temperature range of -20 °C to 1000 °C (-4 °F to 1832 °F). The meter measures 184 mm x 186 mm x 72 mm and weighs approximately 507 g. Supplied complete with test leads, a temperature probe, an inductive clamp, and a carry case. Powered by one PP3 9 V battery (included).
Auto and manual ranging multimeter capable of voltage, current, resistance, diode, temperature and continuity testing. Fitted with a backlit LCD screen, DWELL, Tach, MAX, auto power off, continuity buzzer and data hold features. Supplied with test leads, temp probe, inductive clamp, case and 2x test probes.
Product Key Feature:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specialising in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalogue of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| AC Amps | 6mA/600mA/6A/10A |
|---|---|
| AC Current | 60mA/600mA/6A/10A |
| AC Voltage | 6V/60V/600V |
| Automatic Power Off | Yes |
| Capacitance | 40nF/400nF/4µF/40µF/400µF/4000µF |
| DC Amps | 6mA/600mA/6A/10A |
| DC Current | 60mA/600mA/6A/10A |
| DC Voltage | 6V/60V/600V |
| Diode on/off Test | Yes |
| Dimensions | 184mm x 186mm x 72mm |
| Duty Ratio | Yes |
| Dwell | 4CYL, 6CYL, 8CYL |
| Frequency | 9.999Hz/99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/9.999MHz |
| Resistance (Ohms) | 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ |
| Symbol Unit Data Hold | Yes |
| TACH | RPM4 120-20000, RPM2 60-20000 |
| Temperature | -20 to 1000ºC |
| Temperature Range | -20°C - 1000°C/-4°F - 1832°F |
| Weight | 507g (approx.) |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price | |
|---|---|---|---|---|---|
|
90277 | Draper Spare Test Probe Set for 41817, 41818, 41820, 41821 and 41822 Digital Meters | 1 Unit |
£16.42
£16.10
|
Add |
41822ins.pdf
|
Open Now |
Standard Delivery: UK Mainland Free
Next Day Delivery Available
Delivery Estimate: 2 to 3 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
Sealey TM103 Professional Auto-Ranging Digital Multimeter 11-Function
£81.06
£79.47
2% OFF
Free delivery in UK Mainland
|
Sealey TA305 AC/DC Clamp Metre & Multimeter CAT III 600V
£97.42
£95.51
2% OFF
Free delivery in UK Mainland
|
||||
| Technical Specification | ||||||
|---|---|---|---|---|---|---|
| PRODUCT NUMBER | TA310 | TA311 | 41820 | 02590 | TM103 | TA305 |
A. The Draper 41822 supports auto and manual ranging across AC and DC voltage, AC and DC current, resistance, capacitance, frequency, diode testing, continuity, temperature, DWELL angle and tachometer (RPM) measurement.
A. The meter measures both AC and DC voltage across three ranges: 6 V, 60 V and 600 V.
A. The Draper 41822, used with the supplied temperature probe, measures from -20 °C to 1000 °C (-4 °F to 1832 °F).
A. The DWELL function supports 4-cylinder, 6-cylinder and 8-cylinder engines.
A. The tachometer covers RPM4 from 120 to 20,000 RPM and RPM2 from 60 to 20,000 RPM.
A. The multimeter is supplied with test leads, a temperature probe, an inductive clamp, a carry case and one PP3 9 V battery.
A. Every product comes with a different guarantee and warranty. Warranty details are shown in the product's tech specs or datasheet where available.
