Product Number: 1402-300-20.1019.5
1402-300-20.1019.5 — the Metrol 1402 is a non-locking mini wing handle quarter turn lock finished in black textured powder coat, with a barrel height of 19.5mm. Designed for panel-mount applications, it suits panel thicknesses from 1 to 6mm and requires a 14.1 x 14.1mm cutout. The hinge carries a sealed IP65 rating, making it suitable for environments where dust and water resistance are required.
The handle and housing are manufactured using zinc alloy die casting with a black textured powder coated finish. A mild steel zinc plated cam is included with the lock, making it ready to fit straight from the box. The non-locking configuration means the handle rotates freely to open and close without a key or tool.
The 1402 Non Locking Mini Wing Handle Quarter Turn Lock Black Textured Powder Coated is a durable cam lock designed for secure closure of meter boxes, panel boards, CNC housings, machinery parts. Built with a smooth quarter-turn mechanism, it provides reliable locking for cabinets, access panels, enclosures.
Available with triangle key, double-bit insert, key-locking, key-retaining, this cam lock fits standard UK cut-outs and supports both new installations and replacements.
Key Features:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Manufacturer | Metrol |
|---|---|
| Lock Types | Non Locking |
| Colour/Finish | Black Textured Powder Coated |
| Material | Die Cast Zinc Alloy |
| Panel Cutout | 14.1x14.1mm |
| Panel Thickness | 1 - 6mm |
| Barrel Height | 19.5mm |
| IP Rating | IP65 |
| Cam Option | Cam included |
| Model | 1402 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1418-1-30.1119.5 | 1401-20-20 | 1401-20-30B | 1403-20-20 | 1403-20-30 |
| Type | Lock | Lock | Lock | Lock | Lock |
| Size | 19.5mm | 20mm | 20mm | 20mm | 20mm |
| Finish | Chrome | Chrome | Chrome | ||
| Size Range | 11-25mm | 11-25mm | 11-25mm | 11-25mm | 11-25mm |
A. The 1402 is designed for panels between 1mm and 6mm thick.
A. A panel cutout of 14.1 x 14.1mm is required.
A. The 1402 carries an IP65 ingress protection rating.
A. Yes — a mild steel zinc plated cam is included with the lock.
A. The handle and housing are die cast zinc alloy with a black textured powder coated finish.
A. No — the 1402 is a non-locking quarter turn lock. The wing handle rotates freely without a key or tool.
A. The barrel height is 19.5mm.
A. Yes — WhatsApp us on 07754 288583 with any questions about specifications, suitability, or compatibility.
A. WhatsApp us on 07754 288583 with photos of the item and packaging, and we will resolve the issue in line with our returns policy.
