The BS Truck Buffer is a 60mm-diameter flat rubber bump stop designed to cushion machinery and vehicles against impact shocks from external moving components. With an overall length of 125mm, a body width of 40mm, and a mounting height of 15mm, this two-hole rubber-to-metal bonded buffer absorbs and dissipates energy on contact, reducing impact force transmitted to the host structure and improving both machinery lifespan and operator comfort. Constructed with rubber-to-metal bonded technology, the flat male mounting configuration allows straightforward installation against a surface or secondary moving object. The two fixing holes (D1: 20mm, D2: 8mm) provide secure attachment across a range of mounting faces. By working in compression or shear, or a combination of both. The buffer acts as an elastic element that protects surrounding structures whilst maintaining predictable performance across repeated loading cycles. The 60mm-diameter (dimension A) form factor is suited to applications where a compact yet effective bump stop is required across commercial vehicles, construction equipment, industrial machinery, agricultural equipment, and elevators. It is equally applicable in power generation, marine, railway and mass transit, and automotive environments where controlled impact absorption is essential. Stainless steel metalwork and oil-resistant or high-temperature rubber compounds are available on request for demanding operating conditions. This buffer is available in an additional diameter variant; refer to product D2 for the alternative size option within the range. Supplied as a single buffer unit. No warranty information is available for this product. Manufactured in China.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| col2 | H |
|---|---|
| Overall height H (mm) | 15 |
| Length L (mm) | 125 |
| Width / dimension B (mm) | 40 |
| Number of fixing holes | 2 |
| Overall length / diameter A (mm) | 60 |
| Diameter / thread d1 (mm) | 20 |
| Diameter / thread d2 (mm) | 8 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.49
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
Conical Buffer - Anti-Vibration, Thread Size M12, Max Load 420Kg - 100120MCB30-60
£33.42
£32.76
2% OFF
|
||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 100100MCB31-45 | 100100MCB31-60 | 100100MCB31-70 | 100120MCB31-45 | 100120MCB30-60 |
| Type | Buffer | Buffer | Buffer | Buffer | Buffer |
| Length | 100mm | 100mm | 100mm | 121mm | |
| Height | 120mm | ||||
| Size | 100x100mm | 100x100mm | 100x100mm | 105x121mm | |
| Deflection | 23 | 23 | 23 | 30 | 30mm |
| Diameter | 100mm | 100mm | 100mm | 105mm | |
| Diameter Range | 51-100mm | 51-100mm | 51-100mm | 101-200mm | |
| Length Range | 51-100mm | 51-100mm | 51-100mm | 101-200mm | |
| Shore Hardness | 45 | 60 | 70 | 45 | |
| Thread | M12 | M12 | M12 | M12 | M12 |
| Show More | |||||
A. The BS Truck Buffer has a diameter (A) of 60mm, an overall length (L) of 125mm, a body width (B) of 40mm, and a mounting height (H) of 15mm. It features two fixing holes with a D1 of 20mm and a D2 of 8mm.
A. The buffer uses rubber-to-metal bonded construction to absorb and dissipate energy on contact. It can be loaded in compression, shear, or a combination of both, acting as an elastic element between the host structure and the impacting component to reduce transmitted force.
A. It is suited to commercial vehicles, construction and off-highway equipment, industrial machinery, agricultural equipment, elevators, marine, railway and mass transit, power generation, and automotive applications where controlled impact cushioning is required.
A. Yes. Stainless steel metalwork and oil-resistant or high-temperature rubber compounds are available on request, along with additional and custom sizes.
A. Yes. An alternative diameter variant is available; see product D2 for the other size option in the Truck Buffer range.
A. We accept returns within 30 days of purchase for items that are unused, undamaged, and in their original packaging. Returns are available only for UK-delivered orders and must include proof of purchase. Before returning an item, please contact us at [email protected] to obtain a Return Merchandise Number (RMN).
A. In-stock orders placed before 14:30 Monday to Friday are usually dispatched the same day.
