Product Number: PB335
Variations
Sized for lighter, compact installations, PB335 is a rubber plate buffer measuring 68.6 mm in height (A) with an outer diameter of 84.0 mm, designed to cushion machinery and structures against impact shocks from external moving components. Its relatively shallow 19 mm flange height and compact geometry make it well suited to applications where envelope space is restricted and load demands are moderate, with a maximum rated load of 750 kg. Constructed using rubber-to-metal bonded technology, the buffer works by absorbing and dissipating energy on contact, reducing the impact force transmitted to adjacent structures or acting as an elastic element in direct contact with a surface. The male flat buffer format offers straightforward installation and low-cost shock and vibration absorption in a variety of mounting orientations, loaded in shear, compression, or a combination of both. A 6.9 mm bore (d) and 3.2 mm section (S) complete the dimensional profile, alongside a 46 mm secondary diameter (D2) and 32.0 mm tertiary diameter (D3). This buffer is suitable for use across construction equipment, agricultural machinery, elevators, commercial vehicles, and industrial plant. Sectors including marine, power generation, railway and mass transit, and automotive engineering regularly employ this type of mount to improve machinery lifespan, protect surrounding structures, and improve operator comfort. Custom variants in stainless steel fixings or oil-resistant and high-temperature rubbers are available on request. This plate buffer is part of a broader range of rubber buffers and bump stops.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.49
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
Conical Buffer - Anti-Vibration, Thread Size M12, Max Load 420Kg - 100120MCB30-60
£33.42
£32.76
2% OFF
|
||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 100100MCB31-45 | 100100MCB31-60 | 100100MCB31-70 | 100120MCB31-45 | 100120MCB30-60 |
| Type | Buffer | Buffer | Buffer | Buffer | Buffer |
| Length | 100mm | 100mm | 100mm | 121mm | |
| Height | 120mm | ||||
| Size | 100x100mm | 100x100mm | 100x100mm | 105x121mm | |
| Deflection | 23 | 23 | 23 | 30 | 30mm |
| Diameter | 100mm | 100mm | 100mm | 105mm | |
| Diameter Range | 51-100mm | 51-100mm | 51-100mm | 101-200mm | |
| Length Range | 51-100mm | 51-100mm | 51-100mm | 101-200mm | |
| Shore Hardness | 45 | 60 | 70 | 45 | |
| Thread | M12 | M12 | M12 | M12 | M12 |
| Show More | |||||
A. The PB335 has an overall height (A) of 68.6 mm, an outer diameter (D1) of 84.0 mm, a secondary diameter (D2) of 46 mm, a tertiary diameter (D3) of 32.0 mm, a flange height (H) of 19 mm, a bore diameter (d) of 6.9 mm, and a section (S) of 3.2 mm.
A. The PB335 plate buffer is rated to a maximum load of 750 kg.
A. The PB335 is suitable for construction equipment, agricultural machinery, elevators, commercial vehicles, and industrial machinery. It is also used across marine, power generation, railway and mass transit, and automotive applications.
A. Plate buffers work by absorbing and dissipating energy on contact. They reduce the impact force transmitted from a secondary moving component, or act as an elastic element in direct contact with a surface. The PB335 may be loaded in shear, compression, or a combination of both.
A. Yes — stainless steel metal components and oil-resistant or high-temperature rubbers are available on request, as are additional and custom sizes.
A. Yes — the range also includes PB15, PB238, and PB260, which offer different dimensional profiles and load capacities for a wider spread of installations.
A. The PB335 uses rubber-to-metal bonded construction, providing a secure bond between the rubber element and the metal hardware for reliable energy absorption in service.
