Product Number: AC7109
Worn or incompatible hose connections cause air loss and interrupt workflow. The PCL AC7109 is a 9 mm hose tailpiece from the XF-Euro coupling series, designed to terminate an airline hose and connect it into the XF-Euro quick-release system.
As part of the XF-Euro range, the AC7109 carries series-rated performance of 2200 l/min flow, a maximum working pressure of 35 bar (508 psi), and a temperature range of -40 °C to 100 °C, with a 7.4 mm bore. These are series ratings applicable across the XF-Euro range.
The XF-Euro series is rated for interchange with Cejn 320, Legris 25/26, Norgren 234/238, Rectus 25/26, and Schrader InterCheck 35 couplings, making it a practical choice for workshops running mixed coupling standards on their compressed-air lines.
The AC7109 is manufactured in Sheffield, UK, by PCL, part of HORNGROUP, with Sheffield manufacture dating to 1938.
Product Features :
About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Brand | PCL |
|---|---|
| Part Number | AC7109 |
| Thread Type | Hose Tailpiece |
| Thread Size | 9 mm |
| Nominal Bore | 7.4 mm |
| Flow Rate | 2200 l/min |
| Maximum Working Pressure | 35 bar (508 psi) |
| Temperature Range | -40°C to 100°C |
| Interchange | Cejn 320 / Legris 25/26 / Norgren 234/238 / Rectus 25/26 / Schrader InterCheck 35 |
| EAN | 5014875160115 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £4.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | AC7106/S | AC7108/S | AC7109/S | AC7110/S | AC7113/S |
| Maximum Pressure (psi) | 508 | 508 | 508 | 508 | 508 |
| Connection Type | Quick-Release Coupling | Quick-Release Coupling | Quick-Release Coupling | Quick-Release Coupling | Quick-Release Coupling |
| Coupling Series | XF-Euro | XF-Euro | XF-Euro | XF-Euro | XF-Euro |
A. The AC7109 is the PCL XF-Euro Coupling 9mm Hose Tailpiece. The PCL AC7109 is a 9 mm hose tailpiece from the XF-Euro coupling series, designed to terminate an airline hose and connect it into the XF-Euro quick-release system.
A. Hose Tailpiece.
A. 9 mm.
A. 7.4 mm.
A. 2200 l/min.
A. 35 bar (508 psi).
A. -40°C to 100°C.
A. Cejn 320 / Legris 25/26 / Norgren 234/238 / Rectus 25/26 / Schrader InterCheck 35.
A. Yes — this product is part of a PCL range with sibling variants in alternative sizes, connections or configurations; see the product variants for options.
A. PCL (Pneumatic Components Ltd), the Sheffield, UK based world leader in tyre inflation and compressed air products, part of HORNGROUP.
