Product Number: EXTMP27030
SIP EXTMP27030 NARDI Extreme MP Compressor is a 3.0hp, 270L 3‑phase unit engineered for continuous high volume 10bar compressed air tasks. A 2.20kW (3.00hp) 4‑pole slow‑running motor on 400V 3‑phase drives a 4‑cylinder oil‑free pump delivering 21.20CFM (600L/min) piston displacement and 14.80CFM (424L/min) Free Air Delivery at up to 145psi (10bar) into a large 270L receiver. A V‑Twin cylinder arrangement with direct drive crankshaft, technopolymer piston rings, concentric big end bearings and crankcase air intake diffusion ensure low vibration, reduced contamination and longer pump life, while fan‑shaped stainless steel valves contribute robust sealing. Forced‑air cooling extends runtime, and the adjustable pressure regulator allows operators to tailor output for fibre blowing, process air or light industrial tools. With a relatively low 73dB(A) noise level for its size, this Extreme MP compressor is ideal for industrial-grade applications that need continuous, high volume 10bar oil‑free air from a space‑efficient 270L package.
Key Features:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| ITEM NO | EXTMP27030 |
|---|---|
| Input Supply | 400v 3-PHASE |
| Motor Power | 1x 2.20kW (3.00hp) 4-POLE 1400rpm |
| Receiver Size | 270ltr |
| Piston Displacement | 21.20CFM (600ltr/min) |
| Free Air Delivery (FAD) | 14.80CFM (424ltr/min) |
| Max. Air Pressure | 145psi (10bar) |
| No. of Cylinders | 4 cylinders |
| Noise Level | 73dB(A) |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
More Info
|
Open Now |
Standard Delivery: Channel Island Free
Next Day Delivery Available
Delivery Estimate: 2 to 4 working days
Save Extra With 1 Offer
Compare With Similar Items
A. It is a 3.00hp, 270 litre direct-drive MP compressor for high-volume, low-pressure industrial applications up to 10bar.
A. It uses a single 2.20kW, 3.00hp four-pole motor at 1400rpm running from a 400v three-phase supply for heavy-duty performance.
A. It offers 21.20CFM piston displacement and 14.80CFM free air, around 600 and 424 litres per minute respectively.
A. It is rated up to 145psi, equivalent to 10bar, meeting the needs of many industrial air systems.
A. The V-Twin pump uses robust technopolymer piston rings and stainless valves, providing oil-free operation with low maintenance.
A. They reduce vibration and mechanical stress on the crankshaft, extending pump life under constant industrial duty.
A. It lessens contamination in the crankcase, enhancing valve plate life and ensuring stable compressed-air performance.
A. The large 270ltr tank provides substantial storage, ensuring steady supply during high-volume, low-pressure industrial processes.
A. It suits high volume, low-pressure industrial-grade uses where oil-free air and low noise are required.
A. An adjustable air pressure regulator and pressure cut-off support precise pressure control and automatic compressor shutdown.
A. It runs at about 73dB(A), relatively low for a high-displacement, large-receiver industrial compressor.
