Product Number: 01-009
The CCL 01-009 is a 12V electronic flasher unit rated to a maximum load of 98W, designed to control both indicator and hazard warning functions on a wide range of 12-volt vehicle electrical systems. As a direct-replacement general part, it is suited to professional workshop fitment where a reliable, electronically governed flashing cycle is required.
The unit supports a lamp configuration of four 21W indicator lamps and two 5W side repeater lamps, giving a total combined capability that accommodates the standard bulb layouts found across many 12V vehicle applications. A built-in bulb failure indicator function is incorporated, alerting the driver when a connected lamp has failed - a feature that aids compliance with road-lighting requirements and reduces the risk of undetected lamp outages.
The flasher unit operates on an electronic circuit rather than a thermal or electromechanical relay, which delivers a consistent flash rate regardless of minor supply voltage variation. An optional metal mounting bracket is available, giving flexibility in installation where a secure fixed-position mount is needed within the vehicle's fuse and relay panel area.
This unit cross-references to 13 OE and aftermarket part numbers, including CI: XFL112, HELLA: 4DB, HELLA: 003, HELLA: 750, HELLA: 018, HELLA: 081, HELLA: 171, HELLA: 191, HELLA: 201, INTERMOTOR: 58972, LUCAS SFB: 161, UNIPART GFU: 2213, and VALEO: M11, among others.
The CCL 01-009 is supplied as a single flasher unit and is backed by a 12-month warranty.
About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Type | Electronic |
|---|---|
| Voltage | 12 |
| Side Repeater Lamps | 2 X 5W |
| Indicator Lamps | 4 X 21W |
| Max Load | 98W |
| Function | Indicator & Hazard |
| Bulb Failure Indicator | Yes |
| Bracket Type | Optional Metal |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £2.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
||||||||||
| Technical Specification | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | 01-001 | 01-001H | 01-002 | 01-002H | 01-003 | 01-004 | 01-004H | 01-005 | 01-006 | 01-007 |
A. The 01-009 replaces original-equipment and aftermarket numbers from CI, HELLA, INTERMOTOR, LUCAS SFB, including CI: XFL112; HELLA: 4DB; HELLA: 003; HELLA: 750 (among 13 listed cross-references). Search our cross-referenced catalogue by OEM number to confirm a match, use the selection widget for your machine, or ask Simon.
A. The CCL 01-009 operates on a 12V DC supply and is rated to a maximum load of 98W, supporting a lamp configuration of four 21W indicator lamps and two 5W side repeater lamps.
A. The CCL 01-009 controls both indicator and hazard warning functions within a 12V vehicle electrical system.
A. Yes. The unit incorporates a bulb failure indicator function, which alerts the driver when one of the connected lamps has failed.
A. Yes. Every vehicle and OE cross-reference shown for this part is checked against manufacturer data and backed by our Fit Guarantee. If it is not right, our Fit Guarantee or hassle-free returns have you covered.
