Product Number: 01-012
The CCL 01-012 is a 24-volt electronic flasher unit designed to control both indicator and hazard lamp circuits on commercial vehicles and heavy-duty applications. Built to replace worn or failed original units, it carries a direct cross-reference to Ford part number 6084956, making it a reliable like-for-like replacement for operators sourcing a verified equivalent.
The unit operates at 24V and supports a maximum load of 98W across combined lamp circuits. It is rated for four indicator lamps at 21W each and two side repeater lamps at 5W each, covering the full standard lamp complement on most commercial vehicle installations. A built-in bulb failure indicator alerts the driver when a lamp in the circuit has failed - an important safety feature for vehicles subject to roadworthiness requirements. The unit type is electronic, offering stable flash timing regardless of minor load variations compared with thermal-type units.
An optional metal mounting bracket is available separately for installations that require a fixed bracket rather than a plug-in mounting arrangement, giving the installer flexibility to suit different dash or chassis configurations.
This unit carries cross-references to a broad range of OE and aftermarket part numbers, including CI XFL122, Hella 4DB, Hella 003, Hella 675, Hella 001, Intermotor 58980, Lucas SFB166, Valeo M501, Wehrle 54 401, and Wehrle 54 101, among others - confirming wide aftermarket equivalence across 11 recorded references in total.
Supplied as a single electronic flasher unit. No fitment summary is available from current source data; please verify vehicle compatibility using the OE cross-references listed above before ordering.
About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Type | Electronic |
|---|---|
| Voltage | 24 |
| Side Repeater Lamps | 2 X 5W |
| Indicator Lamps | 4 X 21W |
| Max Load | 98W |
| Function | Indicator & Hazard |
| Bulb Failure Indicator | Yes |
| Bracket Type | Optional Metal |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
||||||||||
| Technical Specification | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | 01-001 | 01-001H | 01-002 | 01-002H | 01-003 | 01-004 | 01-004H | 01-005 | 01-006 | 01-007 |
A. The 01-012 replaces original-equipment and aftermarket numbers from CI, FORD, HELLA, INTERMOTOR, including CI: XFL122; FORD: 6084956; HELLA: 4DB; HELLA: 003 (among 11 listed cross-references). Search our cross-referenced catalogue by OEM number to confirm a match, use the selection widget for your machine, or ask Simon.
A. The CCL 01-012 is rated at 24 volts with a maximum load of 98W. It supports four indicator lamps at 21W each and two side repeater lamps at 5W each.
A. Yes — the CCL 01-012 is rated for both indicator and hazard lamp functions within a single electronic unit.
A. Yes. The unit incorporates a bulb failure indicator that alerts the driver when a lamp in the circuit has failed, supporting roadworthiness compliance.
A. Yes. Every vehicle and OE cross-reference shown for this part is checked against manufacturer data and backed by our Fit Guarantee. If it is not right, our Fit Guarantee or hassle-free returns have you covered.
