Product Number: 01-047
The CCL 01-047 is an Electronic & LED Flasher Unit rated for 12/24V operation with a maximum load of 30W, designed to control indicator and hazard circuits in vehicles equipped with a mix of conventional and LED lamp technology. It is supplied as a direct replacement flasher unit for installations where the existing unit requires renewal or where an LED-compatible flasher is needed.
The unit supports a circuit configuration comprising one 5W side repeater lamp, one 21W indicator lamp, and one LED cluster per channel, making it compatible with mixed-bulb indicator circuits without the need for load resistors in the LED leg. A built-in bulb failure indicator function monitors the circuit and alerts the driver if a lamp becomes inoperative. An optional metal bracket is available for mounting where a direct plug-in installation is not suitable.
Operating across both 12V and 24V systems, the 01-047 is suited to a broad range of vehicle applications including passenger cars, light commercial vehicles, and other 12V or 24V-system machinery requiring indicator and hazard flasher control. The electronic design ensures consistent flash rate even as load characteristics vary across conventional and LED lamp combinations.
For warranty and provenance information: the CCL 01-047 is covered by a 12-month warranty and is manufactured in China.
About PartsForMachines:
PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1-3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Type | Electronic & Led |
|---|---|
| Voltage | 12 |
| Side Repeater Lamps | 1 X 5W |
| Indicator Lamps | 1 X 21W + 1 Led Cluster |
| Max Load | 30W |
| Function | Indicator & Hazard |
| Bulb Failure Indicator | Yes |
| Bracket Type | Optional Metal |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £3.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
||||||||||
| Technical Specification | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| PRODUCT NUMBER | 01-001 | 01-001H | 01-002 | 01-002H | 01-003 | 01-004 | 01-004H | 01-005 | 01-006 | 01-007 |
A. The CCL 01-047 operates across both 12V and 24V electrical systems, making it suitable for a wide range of vehicles and machinery using either voltage.
A. The unit is designed for circuits comprising one 5W side repeater lamp, one 21W indicator lamp, and one LED cluster per channel — covering mixed conventional and LED indicator setups.
A. Yes. The 01-047 incorporates a built-in bulb failure indicator function that monitors the lamp circuit and alerts the driver if a bulb becomes inoperative.
A. Yes. Every vehicle and OE cross-reference shown for this part is checked against manufacturer data and backed by our Fit Guarantee. If it is not right, our Fit Guarantee or hassle-free returns have you covered.
