Product Number: 1420-36037-20
Variations
The Metrol 1420-36037-20 is a quarter turn tri lock fastener featuring a 7mm triangle key operation and a 36mm barrel (grip) height. Finished in black powder coat over a die cast zinc alloy body, it is suited to panel enclosure and cabinet applications requiring a clean, consistent aesthetic and secure quarter-turn latching. The mounting cutout requirement is 20.1 x 20.1 mm, and the lock accommodates panel thicknesses from 1 mm to 22 mm, making it compatible with a wide range of enclosure wall gauges. The latch carries IP65 ingress protection, confirming resistance to dust ingress and low-pressure water jets — a meaningful consideration for industrial cabinet and control panel installations. A range of cam profiles are available for this model series, allowing selection to suit the depth and geometry of the enclosure door being secured. For IP65-rated quarter turn locking across standard panel cutouts, the 1420-36037-20 delivers a straightforward, robust solution.
The 1420-36 Quarter Turn Tri Lock 7mm Triangle with 36mm Grip Height Black Powder Coated is a durable cam lock designed for secure closure of meter boxes, panel boards, CNC housings, machinery parts. Built with a smooth quarter-turn mechanism, it provides reliable locking for cabinets, access panels, enclosures.
Available with triangle key, double-bit insert, key-locking, key-retaining, this cam lock fits standard UK cut-outs and supports both new installations and replacements.
Key Features:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Manufacturer | Metrol |
|---|---|
| Lock Types | Triangle 7mm |
| Colour/Finish | Black Powder Coated |
| Material | Die Cast Zinc Alloy |
| Panel Cutout | 20.1x20.1mm |
| Panel Thickness | 1 - 22mm |
| Barrel Height | 36mm |
| IP Rating | IP65 |
| Cam Option | Range available |
| Model | 1420 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 1401-037-20 | 1401-037-30 | 1401-037-316 | 1401-047-20 | 1401-047-30 |
| Type | Lock | Lock | Lock | Lock | Lock |
| Size | 7mm | 7mm | 7mm | 7mm | 7mm |
| Material | Stainless steel | ||||
| Finish | Chrome | Chrome | |||
| Size Range | Up to 10mm | Up to 10mm | Up to 10mm | Up to 10mm | Up to 10mm |
A. The 1420-36037-20 operates with a 7mm triangle key, in keeping with the tri lock designation of the 1420 model series.
A. A panel cutout of 20.1 x 20.1 mm is required for installation of this quarter turn lock.
A. The lock is designed to suit panel thicknesses from 1 mm to 22 mm, making it compatible with a wide range of enclosure wall gauges.
A. This lock carries an IP65 rating, confirming protection against dust ingress and low-pressure water jets.
A. The body is manufactured from die cast zinc alloy with a black powder coated finish.
A. Yes — the 1420 series offers a range of cam options. Contact us to confirm the cam specification best suited to your enclosure depth and geometry.
