Product Number: 2118-223-20
The 2118-223-20 is a symmetric friction hinge finished in black textured powder coat, measuring 38x40mm and suited to applications requiring controlled rotational resistance with precise positional hold. The unhanded, symmetric orientation means a single component serves both left- and right-hand mounting positions without modification. The hinge body is constructed in die cast zinc with an SS316 stainless steel pin, combining corrosion resistance with robust load-bearing capability. The 4.5mm through holes allow direct screw-in installation. Load capacities are substantial for a component of this size: axial load capacity is rated at 203kg per hinge and radial load capacity at 239kg per hinge, making it a reliable choice where mechanical integrity under sustained load is a requirement.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Colour/Finish | Black Textured Powder Coated |
|---|---|
|
Material; Die Cast Zinc Alloy, SS316 Pin
|
|
| Size | 38x40mm |
| Axial Load Capacity | 203Kg per hinge |
| Radial Load Capacity | 239Kg per hinge |
| Torque | 2.3 N |
| Model | 2118 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Symmetric Friction Hinge with 4.5mm Holes, Black Textured Powder Coated Finish, Size 38x40mm, Torque 2.3N, Metrol - 2118-223-20
|
Open Now |
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 2118-200-20 | 2118-334-20 | 2105-0-90 | 2105-08007-90 | 2105-08011-90 |
| Type | Hinge | Hinge | Hinge | Hinge | Hinge |
| Size | 38x40mm | 4.5mm | 50x57mm | 50x57mm | 50x57mm |
| Material | Nylon | Nylon | Nylon | ||
| Load | 4N | 7N | 1N | ||
| Size Range | Up to 10mm | ||||
A. The hinge body is die cast zinc alloy with an SS316 stainless steel pin, providing corrosion resistance and structural durability.
A. The 2118-223-20 is rated at 203kg axial load capacity and 239kg radial load capacity per hinge.
A. The hinge measures 38x40mm and is supplied in a black textured powder coated finish.
A. Yes. The 2118-223-20 has an unhanded, symmetric orientation and can be mounted in either left- or right-hand positions without requiring a separate variant.
A. The hinge features 4.5mm through holes for screw-in installation.
