Product Number: 2118-200-20
The 2118 Symmetric Friction Hinge (SKU: 2118-200-20) is a screw-in torque hinge measuring 38x40mm, finished in black textured powder coat. Constructed in die cast zinc with a stainless steel SS316 pin, it is suited to applications requiring controlled, friction-held positioning across a range of industrial and engineering environments.
The hinge features an unhanded, symmetric orientation, meaning it can be fitted without regard to left or right-hand configuration. The 4.5mm through holes accept screw fixings, and the black textured powder coat finish provides a durable, consistent surface. The SS316 stainless steel pin offers corrosion resistance appropriate to demanding workshop and enclosure settings.
Load capacity is a defining characteristic of the 2118: it is rated to 203Kg axial load capacity per hinge and 239Kg radial load capacity per hinge, making it suitable for heavier-duty panel, door, and enclosure applications where structural integrity under load is required.
About PartsForMachines:PartsForMachines is a premier e-commerce platform, founded in 2019 in Warwickshire, UK, specializing in aftermarket parts and services for construction, agriculture, and industrial machinery. We offer an extensive catalog of over 500,000 products. Standard delivery: 1–3 working days within UK mainland. We are proud to be an authorised distributor, giving customers extra confidence when purchasing genuine products from us. In addition, we provide a 30-day return policy for eligible items.
| Colour/Finish | Black Textured Powder Coated |
|---|---|
|
Material; Die Cast Zinc Alloy, SS316 Pin
|
|
| Size | 38x40mm |
| Axial Load Capacity | 203Kg per hinge |
| Radial Load Capacity | 239Kg per hinge |
| Torque | Free Operating |
| Model | 2118 |
| Engine Parts | Product Number | Product Name | Recommended Units | Product Price |
|---|
Symmetric Friction Hinge with 4.5mm Holes, Black Textured Powder Coated Finish, Size 38x40mm, Torque Free Operating, Metrol - 2118-200-20
|
Open Now |
Standard Delivery: £5.99
Delivery Estimate: 3 to 5 working days
Save Extra With 1 Offer
Compare With Similar Items
Compare with Similar products
|
|||||
| Technical Specification | |||||
|---|---|---|---|---|---|
| PRODUCT NUMBER | 2118-223-20 | 2118-334-20 | 2105-0-90 | 2105-08007-90 | 2105-08011-90 |
| Type | Hinge | Hinge | Hinge | Hinge | Hinge |
| Size | 38x40mm | 4.5mm | 50x57mm | 50x57mm | 50x57mm |
| Material | Nylon | Nylon | Nylon | ||
| Load | 3N | 4N | 7N | 1N | |
| Size Range | Up to 10mm | ||||
A. The 2118 hinge is rated to an axial load capacity of 203Kg per hinge and a radial load capacity of 239Kg per hinge.
A. The body is die cast zinc alloy and the pin is stainless steel SS316, providing corrosion resistance for demanding applications.
A. The 2118 hinge measures 38x40mm.
A. The hinge features 4.5mm through holes for screw fixings.
A. No. The 2118 is an unhanded symmetric hinge and can be fitted in either orientation without requiring a separate handed variant.
A. It is finished in black textured powder coat, providing a durable surface suitable for enclosure and panel applications.
A. Standard UK mainland delivery is 3–5 working days. Next-day delivery is available on most products and will appear as an option at checkout where eligible.
